Data Sheet

FTY Technology Co.,Ltd
1.5 DC Characteristics
Power Supply Characteristics
Symbol Parameter Minimu
m
Typical Maximu
m
Unit
s
VDD33 3.3V Supply Voltage 3.0 3.3 3.6
V
VDD12 1.2V Core Supply Voltage 1.10 1.20 1.32 V
IDD33 3.3V Rating Current / / 600 mA
The module is limited to OEM installation only.
The OEM integrator is responsible for ensuring that the end-user has no manual
instruction to remove or install module.
This module should be installed and operated with a minimum distance 20cm
between the radiator and your body. OEM integrator shall equipped the antenna to
compliance with antenna requirement part 15.203& 15.204 and must not be co-
located or operating in conjunction with any other antenna or transmitters. And OEM
host shall implement a Class II Permissive Change (C2PC) or a new FCC ID to
demonstrate complied with FCC standard.
The OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed.
This module support 2.4G WLAN 2412-2462MHz which compliance with part 15.247.
The final end product must be labelled in a visible area with the following:
“Contains Transmitter Module “2A3AKFTY8188FTV”
Antenna：
1. Size(mm)
PROVIDER：Dongguan chuancheng Electronics Co., LTD
PART NAME：External antenna
SPEC：wifi 2412-2462MHz
Gain：0dBi
connector :RP-SMA
