-12-
4.3.APP 4.3.1 Installation Download the Tuya Smart app, tap the plus (+) sign to add the home appliance, and select the 2.4 GHz Wi-Fi network. Enter the correct Wi-Fi name and password, and tap Next to connect the vacuum cleaner to the Wi-Fi network. You can configure the Wi-Fi network using either of the following methods: 1. Wi-Fi fast connection: Press and hold the Wi-Fi button on the machine for 3s. The machine beeps and enters the Wi-Fi mode, and the Wi-Fi indicator blinks quickly.
4.3.2 Description of App Icons and Buttons Icons and Descriptions Button Description Entire house cleaning: The vacuum cleaner generates a map of the entire house through sensor scanning, and automatically plans the optimal cleaning path. Configured zone cleaning: You can configure a zone in a certain place on the app map. Then, the vacuum cleaner will automatically move to the zone for cleaning. Press this button to power on the machine. Power button Press this button to pause.
.3.3 Use Instructions Power on and off the machine Tap and hold the button to power on the machine. Then, the power indicator is on, and the vacuum cleaner enters the standby state. When the vacuum cleaner is in a static state, press and hold the button to power off the machine and stop the current cleaning task. Tip: The vacuum cleaner in charging state cannot be powered off. Start cleaning Press the button to start cleaning.
Charge the vacuum cleaner PIN N GO Auto mode: After completing cleaning, the vacuum cleaner automatically returns to the docking station for charging. Manual mode: In pause state, you can press the button to activate the "Return to docking station" mode. When the vacuum cleaner is being charged, the power indicator blinks in breathing manner. Tip: If the vacuum cleaner fails to find the docking station, it automatically returns to the starting point.
More app functions Set a restricted zone or virtual wall You can use the mobile app to set a restricted zone or virtual wall. After the setting is completed, the vacuum cleaner will not enter the restricted zone or cross the virtual wall for cleaning. Tips: * Before using this function, you need to enable the map save mode for the vacuum cleaner in the mobile app. * This function is only used to divide cleaning zones, but cannot be used to block dangerous zones.
Selected zone cleaning Configured zone cleaning You can use the mobile app to select one or more zones for cleaning. The vacuum cleaner will clean one or more rooms based on the zone that you select on the app map. Tips: * Before using this function, you need to enable the map save mode for the vacuum cleaner in the mobile app, and the vacuum cleaner has already generated a map for cleaning. * After cleaning starts, the main unit may move to a place beyond the selected zone.
-19-
-20-
-21-
4 -22-
Left wheel error Left Wheel Fault Put the wheel on the ground Collision buffer stucked Collision Buffer Is Stuck Push heavily the front bumper, the check whether the front bumper can bounces back No water tank inside The Water Tank Is Not Installed Please install the water tank correctly Ground sensor error Ground Sensor Abnormal Clean the ground detector and make sure I'm not lift up Robot not on the gound The Host Is Picked Up Put the robot on the ground Robot trapped The Host Is Trapped
-24-
FCC STATEMENT 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
