Technical Information:
Temperature Probes (RTD) Specification

Parameter Specification
Sensor Type 1000 Ohm RTD Temperature Sensor
Sensor Curve Type TC=3850 ppm/K
Sensor Self-Heating 0.4K/mW at 0 C
Sensor Accuracy +/- 0.15 C minimum including cable
and connector
Range 10 to 45 C(50 to 113 F)
Resolution 0.01 C (0.018 F)
Accuracy +/- 0.1 C (0.18 F)
Host Sampling Rate 1 Hz to 40Hz in integer value
increments
Wire Type 24-28 AWG twisted pairs with
overall shield
Max Sensor Cable Length 6 Feet
VENDYS II Machine Specification

Parameter Specification Description
Min Inflated Pressure 10 mmHg Minimum pressure to
which a cuff can be
inflated and held
Max Inflated Pressure 270 mmHg Maximum pressure to
which a cuff can be
inflated and held
Pressure Resolution 1 mmHg Pressure reported to
host will be to nearest 1
