INSTALLATION (CONTINUED)
WORKSPACE CHAMBER ORIENTATION (ALL UNITS)
Figure 1: Workspace Chamber Layout
PASS BOX ORIENTATION
Figure 2: Pass Box Inner Door and Sliding Shelf
The pass box is provided with an integral sliding shelf to facilitate material transfers. Small items
may be introduced into the chamber via the Arm Port Doors and Sleeve Assemblies using proper
sleeve technique.
Catalyst
Cartridge
Data Plate
