Selling Sheet
TILE & STONE
MADE IN THE USA
Style Number CS82Z 190TS
Construction porcelain porcelain
Tile Type floor tile herringbone mosaic*
Tile Size 12" × 48" 2" × 12"
Edges rectified rectified
Technical
Wear Rating Group 4 4
Break Strength > 400 > 400
Water Absorption % < 0.5 < 0.5
Pre-Consumer Recycled Content 31% 31%
Post-Consumer Recycled Content 9% 9%
DCOF > 0.42 > 0.42
Shade Variation V3 V3
Installation Area Floors, Walls, Exteriors Floors, Walls, Exteriors
A DCOF value of > 0.42 is the new standard for tiles specified for commercial application in standard A137.1-2012, Section 9.6. It replaces the SCOF value of
> 0.60 referenced in ASTM C1028. For more information on the correlation between the two values and about the DCOF AcuTest visit the Tile Council of North
America’s website: www.tcnatile.com
MANUFACTURER’S WARNING:
- Tiles with DCOF AcuTest values less than 0.42 are not recommended for use in areas with wet or slippery conditions. If such tiles are used as a walking surface
where water, ice, oil, grease and/or other substances are present, such a condition could cause a reduction in foot traction and become unexpectedly slippery
resulting in a fall and personal injury. See ANSI standard A137.1 section 6.2.2.1.10, available at www.tcnatile.com/sections6.2.2.1.10.html.
- Water, oil, grease, etc. create slippery conditions. Floor applications with exposure to these conditions require extra caution in product selection. Not for use
on ramps.
- Since there is a shade variation on all natural products, the tile and trim supplied for your particular installation may not match these samples. Final selection
should be made from actual tiles and trim and not from tile and trim samples or color reproductions. Manufactured in accordance with ANSI A137.1 standards.
Colors
152 Titanium 267 Iron 571 Steel 750 Lithium 751 Copper
190TS Herringbone Mosaic
* Herringbone pattern is created by using an A and B piece. If you order 190TS, the A & B come packaged as a set. 1.88 sq. ft. coverage per sheet.
152 Titanium 267 Iron 571 Steel 750 Lithium 751 Copper
FUSION
shawfloors.com
direct 03.14.2019
HS-317901-18
