Selling Sheet
TILE & STONE
DIVA
Nano sealed — does not require sealing on most normal applications
Uses the chemical method as described above. Suitable for most residential, but commercial may benefit
from a sealer application. Sealer recommended if using a high performance or contrasting grout color.
Style Number CS05V CS04V CS03V CS06V CS07V
Construction porcelain porcelain porcelain porcelain porcelain
Tile Type floor tile
polished
floor tile
polished
floor tile
polished
bullnose
polished
mosaic
matte
Tile Size 24" × 24 12" × 24" 12" × 12" 3" × 24" 12" × 12" × 2"
Edges rectified rectified rectified rectified rectified
Technical
Wear Rating Group 4 4 4 4 4
Break Strength > 450 > 450 > 450 N/A N/A
Water Absorption %
< 0.5 < 0.5 < 0.5 < 0.5 < 0.5
DCOF < 0.42 < 0.42 < 0.42 < 0.42 > 0.42
Shade Variation V2 V2 V2 V2 V2
Installation Area Floors, Walls,
Exteriors*
Floors, Walls,
Exteriors*
Floors, Walls,
Exteriors*
Floors, Walls,
Exteriors*
Floors, Walls,
Exteriors*
* exterior wall only
A DCOF value of > 0.42 is the new standard for tiles specified for commercial application in standard A137.1-2012, Section 9.6. It replaces the SCOF value of
> 0.60 referenced in ASTM C1028. For more information on the correlation between the two values and about the DCOF AcuTest visit the Tile Council of North
America’s website: www.tcnatile.com
MANUFACTURER’S WARNING:
- Tiles with DCOF AcuTest values less than 0.42 are not recommended for use in areas with wet or slippery conditions. If such tiles are used as a walking surface
where water, ice, oil, grease and/or other substances are present, such a condition could cause a reduction in foot traction and become unexpectedly slippery
resulting in a fall and personal injury. See ANSI standard A137.1 section 6.2.2.1.10, available at www.tcnatile.com/sections6.2.2.1.10.html.
- Water, oil, grease, etc. create slippery conditions. Floor applications with exposure to these conditions require extra caution in product selection. Not for use
on ramps.
- Since there is a shade variation on all natural products, the tile and trim supplied for your particular installation may not match these samples. Final selection
should be made from actual tiles and trim and not from tile and trim samples or color reproductions. Manufactured in accordance with ANSI A137.1 standards.
Colors
CS07V matte mosaic
100 White 500 Black 100 White 500 Black
shawfloors.com
direct 03.14.2019
HS-317901-18
