Further information
74 Aastra 610d
eud-1093/1.1 – I7.9 – 09.2009
Technical Data
■ Operation
■ Interfaces
■ Battery charge and usage times
■ Ambient conditions
■ Dimensions, weight and surface finish
Standards DECT, GAP
DECT encryption supported
Frequency range 1880 MHz up to 1900 MHz
Transmitted power 10 mW (average power per channel)
Range • up to 300 m outdoors
• up to 50 m in indoors
Headset 2,5 mm jack
Battery capacitance 850 mAh lithium-ion (Li-Ion)
Operating time, talk time up to 12 hours
Operating time, standby up to 100 hours
Charging time in the charging bay 2 hours for fully charged state
Operating temperature 5° C to 40° C
Storage temperature -5° C to +45° C
Class of protection IP 50
Noise Ambient noise filter for loud environments
Hands-free operation Full-duplex hands-free operation
Cordless phone with battery Length x Width x Depth: 135 x 49 x 22.5 mm
120 g
Charging bay without mains adapter Length x Width x Depth: 76 x 75 x 24 mm
40 g
Surface finish (sides and front) Silicone treated
