Personalizing Your Phone
54 Aastra 610d
eud-1093/1.1 – I7.9 – 09.2009
■ Configuring the DTMF mode
You want to be able to use your phone to control other equipment or to access certain services,
such as remote polling of an answering machine or telebanking. For these services you need
the DTMF mode
[a]
.
In the DTMF mode each keystroke generates a tone. If for example you enter a call number dur-
ing a call, your call partner will hear the tone signals.
You can specify whether the DTMF mode should be generally activated or deactivated
[a]
. DTMF
is activated as the default dialling mode.
■ Changing the User PIN
You want to change the PIN used to lock/unlock your phone (see Chapter "Locking your
phone", page 46 and "Unlocking your phone", page 46).
The factory setting is digit combination "0000"; you can select any 2 to 10-digit combination for
your new PIN.
If you have forgotten your PIN, your system administrator can reset it to the factory setting.
Press the navigation key to the right or the Menu softkey.
Settings
Scroll to Settings and press the Select softkey.
General
Scroll to General and press the Select softkey.
DTMF
Scroll to DTMF and activate or deactivate with the Select softkey.
➔ The setting is stored.
Notes:
• Your User PIN applies to all your phones.
• Do not confuse the User PIN with the Admin PIN (see chapter "Changing the Admin PIN", page 55).
Press the navigation key to the right or the Menu softkey.
Settings
Scroll to Settings and press the Select softkey.
General
Scroll to General and press the Select softkey.
New user PIN
Scroll to New user PIN and press the Select softkey.
➔ The display shows User PIN.
