6-16
SUBASSEMBLY
AND PART
INSPECT NATURE OF INSPECTION
SPECIAL
CONSIDERATIONS
MAGNETO AND
ACCESSORY DRIVE
ASSEMBLY
Adapter Gear Bushing Measure bore diameter. Refer to Table of Limits.
Oil Seal Observe that old seal has
been removed without
damage to casting bore.
Studs Look for stripped and
deformed threads.
Gear Teeth Scoring, burning or wear
enough to alter tooth profile.
Shaft Measure diameters and
compare with bushing
diameter.
Refer to Table of Limits.
