Operating instructions

9-4
FIGURE 9-3. FUEL PUMP AND VAPOR SEPARATOR FITTING LOCATIONS
ABC D E
INLET AND
ANGLE°
OUTLET
AND
ANGLE°
MIXTURE
RETURN
AND
ANGLE°
VAPOR
RETURN
AND ANGLE°
DRAIN
AND
ANGLE°
IO-520-M
90
°
ELBOW 90
°
45
°
ELBOW 270
°
90
°
ELBOW 310
°
45
°
ELBOW 250
°
90
°
ELBOW 270
°
45
°
ELBOW 240
°
