Technical data

Flip Closed 27
•
Disconnect the microphone (mute function) when a call is in
progress, press and hold.
•
Mute the ring signal during an incoming call.
•
Put the R380e into silent mode, when in the standby mode press
and hold.
Use the phone book shortcut key to:
•
Enter the phone book directly.
Use the numeric keys to:
•
Enter the digits 0 to 9.
•
Enter associated characters or perform an associated function, for
example:
the 0 key, when held down, enters the international character '+'
the 1 key, when held down dials your voice mail.
•
Enter a short-cut to a Phone book entry, press and hold.
Use the star or asterisk key (*) to:
•
Enter the character
*
.
•
Enter a p (pause) character if held down.
Use the hash key (#) to:
•
Enter the character
#
.
•
Terminate the input of pin and security codes.
•
Recall a phone number from the SIM card phone book (enter the
number of the memory position and then press
#
).
When you successfully connect the R380e to your network operator,
the ‘Standby’ display is shown. On the display a number of different
indicators can be shown if activated.
The Standby display has the following sections:
•
Status indicators in the upper and middle sections of the display.
•
Text and digit indicators in the middle section.
•
Connection signal strength and battery power indicators in the
lower section.
Indicators
Ring volume set to 0. The ringing volume is turned off.
Silent mode. All audible signals are turned off.
Text message received. A message has been received.
Display indicators
NETWORK
18-05-2000
12:00
!
