Service manual

8
R-1502
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
4- 6 MLEVPB016MRF0 M Open lever 1 AD
4- 7 ************* M Oven cavity (Not replaceable part) 1 --
4- 8 PPACGB014MRF0 M Turntable motor packing 1 AA
4- 9 PHOK-B018MRF0 M Latch hook 1 AF
4-10 FANGTB005MRY0 M Unit mounting plate assembly 1 AS
4-11 NFANPB006MRE0 M Fan blade 1 AC
4-12 LBSHC0037WRE0 M Cord bushing 1 AB
4-13 MLEVFB007MRP0 M Mounting lever 2 AC
4-14 PDUC-B112MRP0 M Hood intake duct R 1 AG
4-15 PCOVPB085MRP0 M Waveguide cover 1 AH
4-16 MSPRTA046WRE0 M Latch spring 2 AB
4-17 LANGTB055MRP0 M Chassis support 2 AD
4-18 PDUC-B115MRF0 M Hood duct R 1 AQ
4-19 PDUC-B114MRF0 M Hood duct L 1 AQ
4-20 PDUC-B113MRP0 M Fan duct 1 AH
4-21 PDUC-B117MRF0 M Orifice 1 AC
4-22 PCUSGB043MRP0 M Transformer cushion 1 AC
DOOR PARTS
5 CDORFB304MRK0 M Door assembly 1 BD
5- 1 FDORFB070MRT0 M Door panel assembly 1 AW
5- 2 FCOV-B209MRK0 M Door frame assembly 1 AY
5-2-1 LSTPPB021MRF0 M Latch head 1 AD
5-2-2 MSPRTA046WRE0 M Latch spring 1 AB
5-2-3 LSTPPB037MRF0 M Glass stopper 2 AC
5- 3 GCOVHB044MRF0 M Choke cover 1 AG
5- 4 PSHEPB021MRE0 M Sealer film 1 AE
5- 5 XCPSD40P08000 M Screw : 4mm x 8mm 2 AA
MISCELLANEOUS
6- 1 CFZK-B460MRK0 M Installation material assembly 1 AH
6-1-1 LBSHC0040MRE0 M Grommet 1 AC
6-1-2 LX-BZ0195WRE0 M Toggle screw 4 AC
6-1-3 LX-MZB001MRE0 M Cord holder 1 AB
6-1-4 XBRSD50P60000 M Screw : 5mm x 60mm 2 AA
6-1-5 XOTSD40P12000 M Screw : 4mm x 12mm 3 AA
6-1-6 XTSSD50P35000 M Screw : 5mm x 35mm 6 AA
6-1-7 XWHSD50-16300 M Washer 2 AA
6-1-8 LANG-B002MRP0 M Scale plate 2 AD
6- 2 TINSKB081MRR0 M Top/wall template 1 AD
6- 3 TINSEB296MRK0 M Operation manual/Installation instructions 1 AD
6- 4 QW-QZB025MRE0 M High voltage wire A 1 AT
6- 5 FW-VZB187MRE0 M Main harness 1 AT
6- 6 TCAUAB041MRR0 M DHHS service caution label 2 AA
6- 7 TCAUAB037MRR0 M Monitor caution label 1 AA
6- 8 TCAUAB005MRR0 M Revised DHHS/GRD C/label 1 AB
6- 9 FW-VZB188MRE0 M Low voltage harness 1 AT
6-10 PFIL-B006MRE0 M Charcoal filter 1 AE
6-11 PFIL-B002MRE0 M Grease filter 2 AF
6-12 FFTA-B005MRK0 M Exhaust damper assembly 1 AH
SCREWS,NUTS AND WASHERS
7- 1 LX-CZB016MRE0 M Special screw 3 AA
7- 2 XOTSD40P12000 M Screw : 4mm x 12mm 4 AA
7- 3 XOTSD40P12000 M Screw : 4mm x 12mm 18 AA
7- 4 XHTSD40P08RV0 M Screw : 4mm x 8mm 2 AA
7- 5 LX-CZA038WRE0 M Special screw 6 AA
7- 6 LX-CZ0052WRE0 M Special screw 2 AA
7- 7 LX-BZA041WRE0 M Screw : 4mm x 8mm 4 AA
7- 8 XCPSD30P08000 M Screw : 4mm x 8mm 2 AA
7- 9 LX-BZA041WRE0 M Special screw 1 AA
7-10 XCBSD30P08000 M Screw : 3mm x 8mm 1 AA
