9. Lamp-ECG Combinations
9.1 FQ
®
...HO-Fluorescent
Lamps
Lamp ECG type LxWxH [mm] P
Sys
[W]
lm
1-lp
FQ
®
24W
QTi 1x14/24/21/39 360 x 30 x 21 27 1750
QT-FQ 1x24… CW 360 x 30 x 30 27 1750
QT-FQ 1x24-39…F/CW 360 x 30 x 21 28 1750
QT-M 1x26-42…S 103 x 67 x 31 27 1750
QT 1x24/230-240 237 x 30 x 30 25 1750
QT-ECO 1x18-24…S 80 x 40 x 22 22 1600
QT-ECO 1x18-24…L 150 x 22 x 22 22 1600
2-lp
FQ
®
24W
QTi 2x14/24/21/39 423 x 30 x 21 54 2x1750
QT-FQ 2x25…CW 360 x 30 x 30 51 2x1750
QT-FQ 2x54… F/CW 423 x 30 x 21 53 2x1750
QT-M 2x26-32 … S 123 x 79 x 33 54 2x1750
Lamp ECG type LxWxH [mm] P
Sys
[W]
lm
1-lp
FQ
®
39W
QTi 1x14/24/21/39 360 x 30 x 21 43 3100
QT-FQ 1x39 … CW 360 x 30 x 30 42 3100
QT-FQ 1x24-39…F/CW 360 x 30 x 21 41 3100
QT-M 1x26-42 … S 103 x 67 x 31 40 3000
2-lp
FQ
®
39W
QTi 2x14/24/21/39 423 x 30 x 21 88 2x3100
QT-FQ 2x39…CW 360 x 30 x 30 85 2x3100
QT-FQ 2x24-39…F/CW 423 x 30 x 21 82 2x3100
Lamp ECG type LxWxH [mm] P
Sys
[W]
lm
1-lp
FQ
®
49W
QTi 1x35/49/80 360 x 30 x 21 55 4300
QT-FQ 1x49…CW 360 x 30 x 30 54 4300
2-lp
FQ
®
49W
QTi 2x35/49 423 x 30 x 21 110 2x4300
QT-FQ 2x49…CW 360 x 30 x 30 110 2x4300
Lamp ECG type LxWxH [mm] P
Sys
[W]
lm
1-lp
FQ
®
54W
QTi 1x28/54 360 x 30 x 21 61 4450
QT-FQ 1x54…CW 360 x 30 x 30 61 4450
QT-FQ 1x54…F/CW 360 x 30 x 21 59 4450
2-lp
FQ
®
54W
QTi 2x28/54 423 x 30 x 21 119 2x4450
QT-FQ 2x54…CW 360 x 30 x 30 118 2x4450
QT-FQ 2x54…F/CW 423 x 30 x 21 122 2x4450
Lamp ECG type LxWxH [mm] P
Sys
[W]
lm
1-lp
FQ
®
80W
QTi 1x35/49/80 360 x 30 x 21 89 6150
QT-FQ 1x80…CW 360 x 30 x 30 86 6150
QT-FQ 1x80…F/CW 360 x 30 x 21 87 6150
2-lp
FQ
®
80W
QT-FQ 2x80 423 x 30 x 21 176 2x6150
