Service manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
46
LC-10A3U
SUPPLEMENT
P701 QPLGN1178GEZZ J Plug, 11-pin AC
P751 QPLGN0155FJZZY J Plug, 3-pin(HV) AE
P752 QPLGN0155FJZZY J Plug, 3-pin(HV) AE
P2002 QPLGN1320REZZ J Plug, 13-pin AC
P2003 QPLGN0520REZZ J Plug, 5-pin AB
P2004 QPLGN0420REZZ J Plug, 4-pin AA
SC401 QSOCN0464FJZZY J Socket, 50-pin AH
SC1201 QSOCN0461FJZZY J Socket, 53-pin AH
SC1203 QSOCN0206FJZZY J Socket, 30-pin AF
DUNTKB686FE01
MAIN UNIT (Continued)
1 CCABA2425CE01 J Front Cabinet Ass’y BD
(LC-10A3U-S
A
)
1 CCABA2425CE03 J Front Cabinet Ass’yBD
(LC-10A3U-B
A
)
1-1 Not Available – Front Cabinet —
1-2 GCOVA1817CESA J LED Cover AE
1-3 GCOVA1850CEKA J R/C Cover AG
1-4 HBDGB3133CESK J Badge, "SHARP" AG
(LC-10A3U-S
A
)
1-4 HBDGB3133CESH J Badge, "SHARP" AG
(LC-10A3U-B
A
)
1-5 HDECA0200CESA J Decoration Plate AK
1-6 LANGS0101CEFW J Fixing Metal, x2 AD
1-7 LANGS0102CEFW J Fixing Metal, x2 AD
1-8 MSPRP0200CEFW J Spring AD
1-9 PSPAG2002CEZZ J Spacer, x4 AA
1-10 PSPAG2003CEZZ J Spacer, x2 AA
1-11 PSPAH0704CEUZ J Spacer, x2 AB
1-12 PSPAH1002CEZZ J Spacer, x2 AB
1-13 PSPAH1003CEZZ J Spacer, x1 AB
1-14 PSPAH1004CEZZ J Spacer, x1 AB
1-15 PSPAP0052CEZZ J Spacer, x1 AA
1-16 VSP4030P-558D J Speaker, x2 AQ
1-17 XEBSD20P05000 J Screw, x4 AA
2 CCABB2291CE03 J Rear Cabinet Ass’yBG
2-1
Not Available – Rear Cabinet —
2-2 GDAi-1084CESD J Set Stand AX
2-3 HiNDP5629CESA J Indication Label AE
2-4 JBTN-2051CEKA J Operation Button AH
2-5 JKNBP1166CEKA J Power Button AE
2-6 LANGF9600CEFW J Reinforcement Angle AG
2-7 LX-NZ3047GEZZ J Antenna Nut, x1 AA
2-8 PMLT-0316CEZZ J Spacer, x1 AB
2-9 PMLT-0318CEZZ J Button Spacer, x2 AB
2-10 PMLT-0356CEZZ J Spacer, x1 AB
2-11 PSPAG2004CEZZ J Spacer, x1 AB
2-12 PSPAH1001CEZZ J Spacer, x1 AD
2-13 PZETZ0015CEZZ J Insulating Sheet AG
2-14 QCNW-5760CEZZ J Connecting Cord AP
2-15 QCNW-6047CEZZ J Connecting Cord AC
2-16 XBPSF30P10KS0 J Screw, x4 AB
2-17 XEBSD30P08000 J Screw, x1 AA
3 Not Available – 10" LCD Panel Unit Ass’y —
3-1 RLCDTA019WJZZ 10" LCD Panel Unit CV
å 3-2 KLMP-0116CEZZ J Lamp Unit AZ
3-3 LHLDW1173CEZZ J Wire Holder, x1 AD
3-4 LHLDZA126WJKZ J Panel Holder AR
3-5 PGiDM0100CEZZ J Light Guide Panel AV
3-6 PSHEP0271CEZZ J Diffusion Sheet, x2 AH
3-7 PSHEP0272CEZZ J Reflection Sheet AF
3-8 PSLDMA125WJFW J Panel Shield AK
3-9 PSPAK0035CEZZ J Spacer AB
3-10 QCNW-6105CEZZ J Connecting Cord AD
4 HiNDPA282WJSA Model Label(LC-10A3U-B
A
) AF
4 HiNDPA283WJSA Model Label(LC-10A3U-S
A
) AF
5 HiNDP5803CESA J Caution UL Label AG
6 RCORF0064CEZZ J Core AL
7 Not Available – Serial No. Label —
8 PSLDM4674CEFW J Shield, for FFC AF
9 PZETZA005WJZZ Insulating Sheet AF
10 QCNW-5279CEZZ J Connecting Cord AF
11 QCNW-5285CEZZ J Connecting Cord AF
12 QCNW-5538CEZZ J Connecting Cord AG
13 QCNW-5745CEZZ J Connecting Cord AN
14 QCNW-5951CEZZ J Connecting Cord AF
15 QCNW-5710CEZZ J Connecting Cord AC
16 LHLDW1060CEZZ J Wire Holder, x1 AB
17 LHLDW1173CEZZ J Wire Holder, x1 AD
18 PSPAG2000CEZZ J Spacer, for Button AC
CABINET AND MECHANICAL PARTS
