Service manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
41
LC-10A3U
SUPPLEMENT
DUNTKA143DE01
SWITCH UNIT
DIODES
D4016 RH-EX1271CEZZY J Zener Diode AB
D4017 RH-EX1271CEZZY J Zener Diode AB
D4018 RH-EX1283CEZZY J Zener Diode AB
D4019 RH-EX1283CEZZY J Zener Diode AB
CAPACITORS
C4001 VCCCCY1HH471JY J 470p 50V Ceramic AA
C4002 VCCCCY1HH471JY J 470p 50V Ceramic AA
RESISTORS
R4080 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R4081 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R4082 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R4083 VRS-CY1JF563JY J 56k 1/16W Metal Oxide AA
R4084 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R4085 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R4086 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
SWITCHES
S4009 QSW-K0088GEZZY J MENU AD
S4010 QSW-K0088GEZZY J Channel Up(' )AD
S4011 QSW-K0088GEZZY J Channel Down(")AD
S4012 QSW-K0088GEZZY J MUTE AD
S4013 QSW-K0088GEZZY J BRIGHT AD
S4014 QSW-K0088GEZZY J Volume Up(+) AD
S4015 QSW-K0088GEZZY J Volume Down(-) AD
S4016 QSW-K0088GEZZY J TV/VIDEO AD
S4017 QSW-K0088GEZZY J DISPLAY AD
S4701 QSW-S0213CEZZ J MAIN POWER AE
MISCELLANEOUS PARTS
P4004 QPLGN0564TAZZY J Plug, 5-pin AC
DUNTKA144DE01
R/C, LED UNIT
TRANSISTORS
Q4106 VSDTC144EE/-1Y J DTC144EE AA
Q4107 VSUMG4/////-1Y J UMG4 AC
DIODES
D4120 RH-EX1271CEZZY J Zener Diode AB
D4121 RH-EX1271CEZZY J Zener Diode AB
D4122 RH-PX0368CEZZY J Power/standby Indicator AE
CAPACITORS
C4120 VCKYTV1CF105ZY J 1 16V Ceramic AB
RESISTORS
R4187 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R4188 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4189 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4190 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SC4102 QPLGN0464TAZZY J Plug, 4-pin AC
RMC4101 RRMCU0239CEZZ J Remote Receiver AG
SLD4101 PSLDM4646CEFW J Shield AD
QCNW-5710CEZZ J Connecting Cord AC
