Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
39
LC-10A3U
SUPPLEMENT
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel : les
pi`eces élelectriques qui pr élesentent ces particularit éles, sont rep
éler élee par la marque å et sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle que
la pi`ece recommand élee parl'usine et dans ce manuel de service,
peut provoquer une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone [phone]
★MARQUE: SECTION LIVRAISON DES PIECES DE RECHANGE
DUNTKA142DE01
TUNER UNIT
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKA142DE01 – TUNER Unit —
DUNTKA143DE01 – SWITCH Unit —
DUNTKA144DE01 – R/C, LED Unit —
DUNTKB686FE01 – MAIN Unit —
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCDTA019WJZZ J 10" LCD Panel Unit CV
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU3201 VTUVT2U5UF553 J Tuner BC
TRANSISTORS
Q3201 VSDTC144EE/-1Y J DTC144EE AA
Q3202 VSDTC144EE/-1Y J DTC144EE AA
Q3203 VSDTC144EE/-1Y J DTC144EE AA
Q3204 VS2SC2712Y/-1Y J 2SC2712Y AB
Q3205 VS2SC3928AR-1Y J 2SC3928AR AB
Q3301 VS2SC3928AR-1Y J 2SC3928AR AB
Q3303 VSDTC314TK/-1Y J DTC314TK AC
Q3304 VSDTC314TK/-1Y J DTC314TK AC
Q3401 VS2SC3928AR-1Y J 2SC3928AR AB
Q3402 VS2SC3928AR-1Y J 2SC3928AR AB
Q3403 VSDTC144EE/-1Y J DTC144EE AA
Q3404 VS2SK1467//-1Y J 2SK1467 AE
Q3405 VS2SK1467//-1Y J 2SK1467 AE
DIODES
D3301 VHDDE5SC4M/-1Y J Diode AF
D3401 RH-EX1271CEZZY J Zener Diode AB
D3402 RH-EX1271CEZZY J Zener Diode AB
D3403 RH-EX1271CEZZY J Zener Diode AB
COILS
L3201 VP-1M220J2R9NY J Peaking 22µH AB
L3202 RCiLC0141CEZZY J Coil AF
L3401 VP-1M101J7R7NY J Peaking 100µH AC
CAPACITORS
C3201 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3202 VCEA4U0JN338M J 3300 6.3V Electrolytic AE
C3203 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C3204 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3205 VCCCCY1HH330JY J 33p 50V Ceramic AA
C3207 VCCCCY1HH330JY J 33p 50V Ceramic AA
C3208 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3209 VCKYCY1HB102KY J 1000p 50V Ceramic AA
