Service manual

13
LC-10A3U
SUPPLEMENT
5 White balance adjustment
6 Checking and modifying
the settings
(If E
2
PROM is replaced)
1. Receive the monoscope pattern
signal.
2. Adjust the "RCUTOFF" and
"BCUTOFF" settings on the page 2
of the adjustment process mode to
become the proper white balance.
Do not change the "GCUTOFF"
settings. (It also change the black
level.)
1. Go to the adjustment mode and
check the following settings.
» V0 240
» V16 201
» V16 BIAS 127
» V32 99
» V32 BIAS 127
» V48 47
» V48 BIAS 127
» V63 0
» VGL ADJ 90
» COM 195
1.See if all the settings are as specified.
If not, select an item in question with
[VOL +] or [VOL –] key and adjust the
setting as shown at left.
* An item selected will be highlighted in
yellow.
Adjustment Adjusting conditions Adjusting method
6. Shipping setting list
Channel............................................................................................................................................... 2ch
Air/Cable ............................................................................................................................................. Air
Skip Data_CATV................................................................................................................................. All Skip
Skip Data_AIR .................................................................................................................................... All Skip
Volume ................................................................................................................................................ 20
Picture ................................................................................................................................................. 30
Tint ...................................................................................................................................................... 0
Color ................................................................................................................................................... 0
Black Level ......................................................................................................................................... 0
SHARP................................................................................................................................................ 0
RED-BLUE .......................................................................................................................................... 0
GREEN ............................................................................................................................................... 0
TV Color System................................................................................................................................. N358
AV Color System ................................................................................................................................ Auto
Language ............................................................................................................................................ English
Blue Screen ........................................................................................................................................ Off
EZ Setup Auto Start ............................................................................................................................ On
Sleep Timer ........................................................................................................................................ None
Brightness ........................................................................................................................................... Bright
Auto Power Off ................................................................................................................................... Off
Upside ................................................................................................................................................. Normal
Rigth/Left ............................................................................................................................................ Normal
