SIM5320A_Hardware Design_V1.01 2011-2-29

@Power 10dBm Typical 189mA

WCDMA 900

@Power 23dBm Typical 524mA

@Power 21dBm Typical 417mA

@Power 10dBm Typical 179mA

HSDPA Data

WCDMA 2100

@Power 23dBm CQI=22 Typical 550mA

@Power 21dBm CQI=5 Typical 520mA

@Power -5dBm CQI=22 Typical 270mA

WCDMA 1900

@Power 23dBm CQI=22 Typical 610mA

@Power 21dBm CQI=5 Typical 540mA

@Power -5dBm CQI=22 Typical 270mA

WCDMA 850

@Power 23dBm CQI=22 Typical 550mA

@Power 21dBm CQI=5 Typical 490mA

@Power -5dBm CQI=22 Typical 220mA

WCDMA 900

@Power 23dBm CQI=22 Typical 550mA

@Power 21dBm CQI=5 Typical 490mA

@Power -5dBm CQI=22 Typical 220mA

5.4 EMC and ESD Notes

EMC tests should be performed to detect any potential problems. Possible harmful emissions radiate by

the application to the RF receiver in the receiver band. RF emissions interfere with audio input/output. It is

recommended to shield the sensitive components and trace with common ground and user can add beads

where necessary.

Normally SIM5320A is mounted on customer host board. Although some ESD components have been

added in SIM5320A, to prevent ESD, user should put some ESD components on customers’ board. The

ESD components should be placed beside the connectors which human body might touch, such as SIM

card holder, audio jacks, switches, keys, etc. The following table is the SIM5320A ESD measurement

performance; the results are from SIMCom EVB test.

Table 45: The ESD performance measurement table (Temperature: 25 , Humidity:℃ 45%)

Part Contact discharge Air discharge

VBAT,GND ±4KV ±6KV

UART,USB ±2KV ±6KV

Antenna port ±4KV ±6KV

Other ports ±2KV ±2KV
