● Method 1: Power off SIM5320A by pulling the POWER_ON pin down
● Method 2: Power off SIM5320A by AT command
User can power off the SIM5320A by pulling POWER_ON down for a specific time. The power off
scenario is illustrated in the following figure.
Figure 19: Power off timing sequence
Table 8: Power off timing
Parameter Description Time value Unit
Toff The time pulling POWER_ON down to power off 0.5< Toff<5 s
TpD- The time to indicate disconnecting from the network >7 s
Tpw- The time to indicate the module power off completely >7.5 s
Tuart_off The time to disable UART >6 s
Tusb_off The time to disable USB >7.5 s
User can also use the AT command
“AT+ CPOF ” to power down the module. After that, the AT commands
cannot be executed any longer. The module enters the POWER DOWN mode, only the RTC is still active.
For details, refer to Document [1].
