User's Guide

self-starting base station mode.
[Radio] The differential data format of the built-in
radio transmission and the data forwarding switch,
sending differential data, need to be set to the
self-starting base station mode, the radio module
must be turned on power-up, set power and
frequency, etc.
8.Module
Click the "Module" on the
left side of the page. You
can check:
 [WiFi settings]
 [Bluetooth settings]
[WiFi settings] Set power status, power-on start-up,
WIFI mode, SSID, MAC.
[Bluetooth settings] The local name, MAC address,
PIN, discoverable status is displayed in the summary;
9.Firmware
Click the "Firmware" on the
left side of the page. You
can check:
 [Firmware
information]
 [Firmware upgrade]
 [Hardware
information]
[Firmware information] Displays the current
firmware version of the firmware, the firmware
release date.
[Firmware upgrade] Web firmware upgrade, please
refer to the details [CM3 series firmware upgrade
method].
[Hardware information] For developers to
understand the receiver hardware information,
including motherboard, core board, PN, SN, board
firmware version number.
9.Other
settings
Click the "Firmware" on the
left side of the page. You
can check:
 [Receiver
registration]
 [Language
switching]
 [Network services]
 [Account
management]
[Receiver registration] Implements the function of
registering the receiver.
[Language switching] You can switch the web
language.
[Network services] Including FTP service and HTTP
two settings, FTP service can be set to the machine
FTP storage username password, HTTP port number,
default 80, do not modify。
[Account management] Set your username,
password, and change your password.
5 Operation and accuracy of static operating mode
5.1 Static measurement job steps
Step1Set up the instrument
The instrument is placed on the measuring point, the height is moderate, the scaffold is solid, and the level is
strictly aligned to the middle.
Step2Measures antenna height
