User's Guide

ftp push -- You can set ftp push to turn off
[FTP push settings]You can set up 3 FTP servers,
click to modify the pop-up FTP push settings
window can set the server IP, port, remote
directory, local push directory, server description,
username, password. FTP push can set up the FTP
server to be pushed, otherwise select Off.
[FTP push records]A list of realistic FTP push
records.
[Data download]
6.IO settings
Click the “IOSettings” on
the left side of the page
[RTK client] Connection protocols include NTRIP,
APIS_ROVER, which support CORS and handbook
network mobile stations, respectively.
Under the NTRIP protocol, CORS can be logged in
by setting the IP, port, source list, username,
password.
under the APIS_ROVER protocol, you can log on to
the remote network server and use it as a mobile
station for the network RTK.
[TCP/UDP_Client/Ntrip Serve]
1、[TCP/UDP_Client/Ntrip Serv] The protocol is
optional for TCP,UDP,NTRIP1,NTRIP2 protocols.
2、A "remote IP" is the address and port number
of a PC received at the remote end, which is the
destination address of the receiving terminal.
3、The data send port can be set up in the port
number.
4 、 Differential data, raw data, astrological
data,HCPPPdata,HRCdata,GPGGA,GPGSV,GPRMC,
GPZDA,GPGST,GPVTG,GPGSA,GPPOS are the
machine support output data types, can be set
whether the output and the output frequency.
5、After setting the parameters, click "OK" at the
bottom of the page to save the current settings,
data entries cannot be edited during data
sending, details can be viewed under the detailed
button.
[TCP/serve/Ntrip caster] The Ntrip protocol and
the TCP protocol are supported in the connection
protocol, and the Ntrip protocol allows the user to
log directly into the CM3 series to obtain data.
[Serial Port] Data output Baud Rate, Differential
Data,RawData,HCPPPData,HRCData,GPGGA,GPGS
V,GPRMC,GPZDA,GPGST,GPVTG,GPGSA,GPPOS are
