User Manual

IWI666‐B 802.11n 300M+USB Charge+ Internal Battery+ Internal 16G SSD Wireless Router
Shanghai DareGlobal Technologies Co., Ltd TEL：800‐820‐8756
Power supply by Built-in battery Red
Wi-Fi LED Color
Wi-Fi is working and has accessed to Internet Green
Wi-Fi is working but hasn’t accessed to Internet Orange
Wi-Fi is not working Red
Battery LED
Color
Battery power over 95% Flashing Green
Battery power 95%-70%
Green
Battery power 70%-40% Orange
Battery power 40%-5% Red
Battery power 5% or less Flashing Red
Tips:
Under the condition of reset, three lights turn orange.
In the process of upgrading, the Wi-Fi LED flash red and green alternately.
Chapter 2 User operation guide
2.1 Hardware operations
2.1.1 Power switch button
2.1.1.1 Power on:
Mode① While IWI666-B is plugged into power adapter, the device starts up
automatically；
Mode ② Device is supplied by battery, press the switch button 1s before releasing,
device performs starting-up operation.；
2.1.1.2 Power off：
Mode ① Device is plugged out the power supply, and then the device performs
shutdown process.
Mode ② The device is working and supplied with battery, press the switch button 1s
before releasing, the system performs shutdown process；
Notes：Power Saving Mode: During the shutdown process, if there are USB Ports
containing mobile phone or some other recharging devices, devices automatically enter power
saving mode (power and Wi-Fi lights turn red). Unplugging the recharging devices such as mobile
phone, the system automatically shuts down the machine；
2.1.1.3 Launch Fast-Charging/Power Saving Mode:
The Fast-Charging Mode: The machine plug in the power, and the system powered on,
press the switch button 1s before releasing. The system enters the fast charging mode
(Wi-Fi LED is red), the battery or the USB charging port charge mobile phones and
other devices, the system automatically shuts down the machine when finished the
charge.
