Receiver Section 6-9
SmartPoint Module for the Elster A3 Meter ECMTM40000
6.2.13 Set Preferred Buddy Id
A command to set the 4 byte preferred buddy address for this meter.
6.2.14 Set Company Meter Number
A command to set the 13 byte customer number.
Byte
(Bits)
Field
0 Repeat Level / Status
1 App Sequence
2 App Code: 7 – Command Message
3 Command Type: 12 – Set Preferred Buddy Id
4-7 Buddy Routing Address
8-11 Preferred Buddy Address
12-31 (reserved)
Byte
(Bits)
Field
0 Repeat Level / Status
1 App Sequence
2 App Code: 7 – Command Message
3 Command Type: 13 – Set Company Meter Num-
ber
4-7 Buddy Routing Address
8-21 ASCII Customer Meter Number
22-31 (reserved)
