Receiver Section 6-7
SmartPoint Module for the Elster A3 Meter ECMTM40000
6.2.10 Set Transmitter Id
A command to change the endpoints transmitter id.
10- Test Meter Read On Air Meter Reading Message (no alarms) preceded
by a meter reading
11 – Single Tier Data Meter Read Single Tier Data Message – The byte after the ping
type contains the Tier Information byte for the desired
tier. Note: Does not re-read meter.
14 – Extended Setup On Air Extended Setup Message
15 – Setup On Air Static Setup Message
16 – Binding On Air Binding Message
20 – Single Tier Data Meter Read,
re-read meter
Single Tier Data Message – The byte after the ping
type contains the Tier Information byte for the desired
tier. Note: Does Re-read meter.
21 – Demand History On Air Demand History Message
23 – LP Meta Data On Air LP Meta Data Message
24 – LP Block Data On Air LP Block Messages - The byte after the ping
type contains the requested block. As many messages
as are required to send a complete block are sent
25 – LP Block Data – Single Mes-
sage
Single On Air LP Block Message - The byte after the
ping type contains the requested block. The following
byte contains the message number (0, 1, 2, 3)
Byte
(Bits)
Field
0 Repeat Level / Status
1 App Sequence
2 App Code: 7 – Command Message
3 Command Type: 9 – Set Transmitter Id
4-7 Buddy Routing Address
8-11 New Transmitter Id
12-31 (reserved)
