Receiver Section 6-4
SmartPoint Module for the Elster A3 Meter ECMTM40000
6.2.5 Set Latitude and Longitude
A command to force the device update its position:
6.2.6 Set VoltVoltage Quality settings:
Byte
(Bits)
Field
0 Repeat Level / Status
1 App Sequence
2 App Code: 7 – Command Message
3 Command Type: 3 – Set Lat / Long
4-7 Buddy Routing Address
8-11 Latitude
12-15 Longitude
16-31 (reserved)
Byte
(Bits)
Field
0 Repeat Level / Status
1 App Sequence
2 App Code: 7 – Command Message
3 Command Type: 4 – Set Voltage Quality Set-
tings
4-7 Buddy Routing Address
8 Minimum Click Count Duration
9(0:5) Minimum Voltage Threshold
9(6:7) Voltage Averaging Window
10(0:3) Outage Time Threshold
10(4:) Restored Time Threshold
11-31 (reserved)
