Setup and Configuration 5-10
SmartPoint Module for the Elster A3 Meter ECMTM40000
The Real Time field contains the number of elapsed seconds since the top of the hour ( 0 -3599 ) from the
perspective of the device.
5.5 Set Device ID (0x92)
Set the 28 bit device Id (factory only, not available in setup tool). The command has the following format:
17-18
Transmit Channel C
19-20
Transmit Channel D
21-22
Receiver Channel
23-24
Boost Mode Channel
25 (0:3)
Boost Mode Sub-Channel
25 (4)
Boost Mode Hopping
25 (5:7)
Transmit Channel Mask
26 (0:3)
Transmitter Operational Mode
26 (4:6)
Receiver Operational Mode
26 (7)
Enable Encryption
27-28
Programmer Id
28 (7)
Disable Compression
29-30
TXCO Correction
31-34
Latitude
35-38
Longitude
39-41
Meter Reading
42
Minimum Click Duration
43(0:5)
Minimum Voltage Threshold
43(6:7)
Voltage Averaging Window
44(0:3)
Outage Time Threshold
44(4:7)
Restored Time Threshold
45-46
Real Time
Msg
Type
Length Bytes 0-3 CRC
0x92 4 Device Id
Byte (Bits) Field
