Setup and Configuration 5-6
SmartPoint Module for the Elster A3 Meter ECMTM40000
5.2.12 Enable Encryption
5.2.13 Programmer ID
A 16-bit field code containing the Id number of the handheld programming device that set up this
device.
5.3 Setup Messages
5.3.1 Setup Messages
The end point device is configured via several setup messages which are defined in the following
sections and are listed in the following table:
Setting AE-256 Encryption
0Off
1On
Type Message
0x91 Status Request
0x92 Set Device Id
0x93 Static Setup
0x94 Set TCXO Correction
0x95 Set Latitude / Longitude
0x96 Set A/D Converter Calibration
0x97 Set Voltage Quality Thresholds
0x98 Set Encryption Key
0x99 Set Real Time
0x9A Send Data
0x9C Ping
0x9D Set Customer Meter Number
0x9E Set Customer ID
0xAF Reset FlexNet Module
0xD0 Test Command
0xD1 Command Pass Through
