Setup and Configuration 5-4
SmartPoint Module for the Elster A3 Meter ECMTM40000
Transmit Frequency (MHz) = Base Frequency (MHz) + (Transmit Frequency
Channel * .00625)
5.2.6 Receive Frequency Channel
A 16-bit field (13 used) representing the receive channel from 0-8000 spanning 50 MHz of bandwidth
in 6.25 kHz slots. The Receive Frequency is determined using the following equation:
Receive Frequency (MHz) = Base Frequency (MHz) + (Receive Frequency Channel * .00625)
5.2.7 C&I Mode Channel
A 16-bit field (13 used) representing the C&I Channel from 0-8000 spanning 50 MHz in 6.25 KHz
steps. The C&I Mode Frequency is determined using the following equation:
C&I Mode Frequency (MHz) = Base Frequency (MHz) + (C&I Mode Channel * .00625)
5.2.8 Priority Mode Channel
A 16-bit field (13 used) representing the Priority Mode Channel from 0-8000 spanning 50 MHz in 6.25
KHz steps. The Priority Mode Frequency is determined using the following equation:
Priority Mode Frequency (MHz) = Base Frequency (MHz) +
(Priority Mode Channel * .00625)
5.2.9 Transmit Channel Mask
A 3-bit field containing bit flags to indicate if Transmit Channels B, C or D are active. A 1 in a bit field
indicates that that transmit channel is active. The following table defines the Transmit Channel Mask
field:
Bit Transmit Channel
0 Transmit Channel B Active
1 Transmit Channel C Active
