On Air Message Types 4-28
SmartPoint Module for the Elster A3 Meter ECMTM40000
4.17.5 Click History
4.17.6 Load Limit Status/Threshold
4.17.7 Advanced Voltage Quality Settings
Ping Response to
Data Byte (Bits)
Field
0-3 Epoch Time of Click 1
4-7 Epoch Time of Click 2
8-11 Epoch Time of Click 3
12-15 Epoch Time of Click 4
16-19 Epoch Time of Click 5
17-20 Epoch Time of Click 6
21-24 Epoch Time of Click 7
25-26 Reserved
Ping Response to
Data Byte (Bits)
Field
0 (0:6) (reserved)
0 (7) Enable Current Limit
1
Current Limit (1-255 A)
(1 amp steps)
3-26 (reserved)
Ping Response to
Data Byte (Bits)
Field
0 Brownout Voltage Threshold
1 (0) Enable Brownout Reporting
1 (1) Enable Over Rated Current Reporting
1 (2) Enable Reverse Power Reporting
1 (3:7)-26 Reserved
