On Air Message Types 4-25
SmartPoint Module for the Elster A3 Meter ECMTM40000
18 (B) Tier 3: Last 15-Min Interval (1-96)
19 (B) Tier 4: First 15-Min Interval (1-96)
20 (B) Tier 4: Last 15-Min Interval (1-96)
21 (0:3) Weekend Tier
21 (4:7) Holiday Tier
22-26 (reserved)
Ping Response to
Data Byte (Bits)
Field
