On Air Message Types 4-24
SmartPoint Module for the Elster A3 Meter ECMTM40000
4.17.1 Demand Enable Status/Interval Configuration
4.17.2 TOU Enable Status/Tier and Season Configuration
Ping Response to
Data Byte (Bits)
Field
0 (0) Message Sequence Number
0 (1:7) Number of Messages
1 LP Read Failed
2 LP Samples, from ANSI C12.19 table ST-64
3
(Last Message Only) The ANSI C12.19 Sequence
Number of the Block Requested
4 - 26 Reserved
Ping Response to
Data Byte (Bits)
Field
0(0) TOU Enabled
0(1:7) (reserved)
1-2(0) Season A: Start Date (Julian Day 0-365)
3 (A) Tier 1: First 15-Min Interval (1-96)
4 (A) Tier 1: Last 15-Min Interval (1-96)
5 (A) Tier 2: First 15-Min Interval (1-96)
6 (A) Tier 2: Last 15-Min Interval (1-96)
7 (A) Tier 3: First 15-Min Interval (1-96)
8 (A) Tier 3: Last 15-Min Interval (1-96)
9 (A) Tier 4: First 15-Min Interval (1-96)
10 (A) Tier 4: Last 15-Min Interval (1-96)
11-12(1) Season B: Start Date (Julian Day 0-365)
13 (B) Tier 1: First 15-Min Interval (1-96)
14 (B) Tier 1: Last 15-Min Interval (1-96)
15 (B) Tier 2: First 15-Min Interval (1-96)
16 (B) Tier 2: Last 15-Min Interval (1-96)
17 (B) Tier 3: First 15-Min Interval (1-96)
