4.11.10 Alarm Data
All bits, bytes 13-14. The Alarm provides 16 bit fields, each of which can represent a different failure
mode as shown in the table below.
4.11.11 Time of Last Power Failure
The time and date of the last power failure, as defined in the table below:
4.11.12 Total # of Outages
The total number of outages since meter was configured.
Byte,
Bit
Description
13, 0 Meter Unprogrammed
13, 1 Configuration Error
13, 2 Self check Error
13, 3 RAM Failure Error
13, 4 ROM Failure Error
13, 5 NONVOL Error
13, 6 Clock Error
13, 7 Measurement Error
14, 0 Low Battery Error
14, 1 Low Loss Potential
14, 2 Demand Overload
14, 3 Power Failure
14, 4-7 Reserved
Byte Description
15 Month (1-12)
16 Day (1-31)
17 Hour (0-23)
18 Minute (0-59)
