4.11 C&I Alarm Message – App Code 16
4.11.1 Application Data
This message contains alarm data from the meter and is also used to report power failures.
4.11.2 Voltage Phase A,B, and C
The current voltage reported by the meter for all three phases:
Voltage Phase n = Value*2
4.11.3 Click Count
An 8 bit field containing the number of times AC voltage loss has been detected by the meter.
4.11.4 Time Since Event
An 8 bit fields containing the time in 6 second resolution since a power failure or power restoration
actually occurred.
App Data
Bytes
Data
0 Voltage Phase A
1 Voltage Phase B
2 Voltage Phase C
3 Click Count
4 Time Since Event
5-6 Extended Time Since Event
7-9 Current Reading
10 Device Temperature
11 µP Errors
12 Lock Errors
13-14 Meter Alarm Flags
15 # Manual Demand Resets
16-19 Time of Last Power Fail
20-23 Time of Last Power Restore
24 Total # of Outages
25 Flags
