On Air Message Types 4-15
SmartPoint Module for the Elster A3 Meter ECMTM40000
4.10 C&I Tunneling Read—App Code 15
Message Format: This message is used to transmit raw C12.19 table data in response to a C12.19 Table
Read Command. The Application Sequence number of this message matches that of the Table Read
Command. The C12.19 table and offset of the raw data also match the command. If the number of returned
bytes is 0, then an error has occurred reading the table.
App Data
Bytes
Data
0 Number of returned bytes
1-27 Raw Data bytes
