User Manual

Multi-Function Gigabit Wireless-N Client Bridge
Version 1.0
58
Appendix A – Specifications
Hardware Summary
Physical Interface LAN: One 10/100/1000Mbps
Reset Button
Power Jack
WPS push button (Wi-Fi Protected Setup)
LEDs Status Power/ Status
LAN (10/100/1000Mbps)
WLAN (Wireless Connection)
Power Requirements
Power Supply: 100 to 240 VDC ± 10％, 50/60 Hz (depends on
different countries)
Active Ethernet (Power over Ethernet, IEEE802.3af)- 48
VDC/0.375A
Device: 12V/1A
Regulation
Certifications
FCC Part 15/UL, CE
Radio Specifications
Frequency Band
2.400～2.484 GHz
Media Access Protocol
Carrier sense multiple access with collision avoidance
(CSMA/CA)
Modulation Technology
z OFDM: BPSK, QPSK, 16-QAM, 64-QAM
z DBPSK, DQPSK, CCK
Operating Channels
11 for North America, 14 for Japan, 13 for Europe
Receive Sensitivity
(Typical)
z IEEE802.11n
MCS8 @ -91dBm
MCS15 @ -74dBm
z IEEE802.11g (3RX)
6Mbps@ -92dBm
54Mbps@ -75dBm
z IEEE802.11b (1RX)
1Mbps@ -93dBm
11Mbps@ -91dBm
Available transmit power
z IEEE802.11n @ 17dBm
z IEEE802.11g @ 23dBm
z IEEE802.11b @ 15dBm
Antenna *3
Omni-directional external antenna
TNC type; Peak Gain = 5 dBi
Software Features
Topology Infrastructure/Ad-Hoc
20dBm
