Technical data

DRIVE PARTS BREAKDOWN

ITEM PART NO. DESCRIPTION DIMENSION DIN QTY

1 SH1710500010 Capacitor motor 1

2 SH9917985032 Oval head cap screw M 5x10 985 4

3 SH1270030010 Toothed wheel z=65 m=1,25/z=13 m=2 D=92,1 B=47 1

4 SH1270030020 Bolt RD 16x53,25 1

5 SH1270030055 Toothed wheel z=13 m=2,75 D=42 B=19,7 1

6 SH1270030045 Toothed wheel z=13 m=2,75 D=70 B=27,2 1

7 SH1270030030 Toothed wheel z=50 m=2 D=110 B=20 1

8 SH1270030060 FRAME 234,5X118X47 1

9 SH9917500003 Screw M 4X55 500 6

10 SH9910127004 Spring washer A 4 127 6

11 SH1270030070 Cover Plate BL 1,5x118,4228,5 1
