Security Engineered Machinery Co., Inc OPERATIONAL & MAINTENANCE MANUAL SEM Model 126C/2 Rev. 0 As of January 1, 2008 Security Engineered Machinery Co., Inc NATIONWIDE SERVICE Phone Toll Free 1(800)225-9293 Email: Service@SEMSHRED.COM Fax: (508)366-6814 Website: WWW.SEMSHRED.
TABLE OF CONTENTS Index-----------------------------------------------------------------------------------------------------------------------1 Safety Procedures & Instructions-----------------------------------------------------------------------------------2-4 Technical Data/Installation-------------------------------------------------------------------------------------------5-6 Malfunctions-------------------------------------------------------------------------------------------------------------7-9 Us
***IMPORTANT SAFETY PROCEDURES*** Your new paper shredder incorporates powerful, heavy duty cutting mechanisms. Serious and permanent injury may result if proper precautions are not followed. 1. This equipment should never be operated by children or individuals untrained in or incapable of understanding the safety precautions! 2. Do not reach into the feed opening for any reason! Never insert fingers, hands, other extremities or objects not meant to be shredded into the feed openings! 3.
SAFETY INSTRUCTIONS 1. 2. 3. 4. Read all instructions before start-up of the paper shredder. Save these instructions for later use. Follow all warnings and instructions marked on the products! Before cleaning the paper shredder: a. Switch paper shredder off, unplug it from the power source b. Clean with a damp cloth using a mild soap and water solution, the use of abrasives, petroleum ether, benzine or diluting agent is forbidden. 5.
SAFETY INSTRUCTIONS Cont…… Risk of injury! Never insert hand, fingers or any foreign object into the paper feed opening Risk of injury by pulling in! Keep long hair, loose articles of clothing, ties scarves, jewelry, etc. away from feed opening. Material with the tendency to form loops, eg. tapes, strapping material, etc. must not be shredded.
TECHNICAL DATA Shred Size: Max. No. of Sheets: Shredding Speed: Throat Width: Power: Voltage: Dimensions: Weight: 1 x 5 mm Up to 5 Sheets 27 FPM 10" 5/8 HP @ 7 Amps 115V/1/60 HZ 33"H x 18"W x 14"D 70 lbs. INSTALLATION 1 Connect plug to 115 Volt wall outlet 2. Paper shredder must only be operated in upright position 3. Set up paper shredder so that the ventilation slots are free 4.
INSTALLATION Cont…. Open front door and pull out frame with bag for shredded material. Fold new bag around frame and allow to, overlap by approximately 20cm. Push frame with guide and bag into bottom frame, close front door. Read operating instructions before pulling shredder into operation. Insert main plug in power socket.
TROUBLESHOOTING If the paper shredder does not work properly, please check the following: 1. Is the main plug inserted into the main power outlet? 2. Is the paper shredder turned on? 3. Is the paper shredder front door closed? 4. Is the front door closed? 5. Is the bag full? 6. Is there a paper jam? 7.
TROUBLESHOOTING Cont… Electric Motor Overheated Red LED on Control panel lights • Paper shredder switches off automatically Tap rocker switch pos.2 • Rocker switch resets to zero position Allow paper shredder to cool sown for approximately 15 to 20 minutes Press rocker switch pos. 1 Shredder Material Container Full Red LED on control panel lights • Paper shredder switches off Remove full shredded material bag and insert new bag Close front door of paper shredder Tap rocker switch pos.
TROUBLESHOOTING Cont… Run cutting system forwards and backwards (pos.1-pos. 2) several times without feeding paper. Paper dust and particles are shaken off. USING AND ORDERING SPARE PARTS Only use original SEM spare part replacements We guarantee their quality and functional reliability Warranty claims on parts and/or service must be approved by SEM's Customer Service Manager HINTS FOR ORDERING SPARE PARTS The spare parts shown on the following pages have part numbers.
CABINET/HOUSING For NATIONWIDE SERVICE Call 1(800)225-9293 10
CABINET /HOUSING PARTS BREAKDOWN ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 PART NO.
CUTTING HEAD For NATIONWIDE SERVICE Call 1(800)225-9293 12
CUTTING HEAD PARTS BREAKDOWN ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PART NO.
DRIVE For NATIONWIDE SERVICE Call 1(800)225-9293 14
DRIVE PARTS BREAKDOWN ITEM 1 2 3 4 5 6 7 8 9 10 11 PART NO.
ELECTRIC For NATIONWIDE SERVICE Call 1(800)225-9293 16
ELECTRIC PARTS BREAKDOWN ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 PART NO.
WIRING DIAGRAM For NATIONWIDE SERVICE Call 1(800)225-9293 18
