Flat Panel LCD Television LC-55TD5 Instruction Manual En SERIES Read all of these instructions carefully before using this television. Keep these instructions in a safe place for future reference.
IMPORTANT INFORMATION English The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric to persons. The exclamation point within an equilateral triangle is interded to aler the user to the presence of important operating and maintenance (servicing) instruction the literature accompanying the appliance.
IMPORTANT INFORMATION 10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11.Only use attachments / accessories specified by the manufacturer. 12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over. English 13.
Screws:9xMB5X10
If the Westinghouse Customer Service.
SAFETY PRECAUTIONS English Keep the TV dry and away from humidity. Keep the TV away from heat sources . Unplug the TV before cleaning it. Do not use solvent or liquid to clean the TV. Only clean the TV with a soft and dry cloth. In case of troubleshooting, do not use spare parts other than those suggested by the manufacturer. Using inadequate spare parts can lead to electric shocks, short-circuits , fire or other incidents. Unplug the TV during lightning storms or when unused for long periods of time.
CONTENTS CONTENTS INPUT 1 2 3 4 5 6 7 8 9 0 PICTURE SOUND SLEEP DISPLAY CH+ VOL+ MUTE CH- VOLEXIT MENU OK ENTER CC MTS ASPECT FAV
OVERVIEW 6. OVERVIEW INPUT Blue when TV is powered on. Red when TV is powered off. No color when power switch is turned off.
below. into AC IN Make sure the power switch is turned on, which is located at the back of the TV.
INPUT TUNER TV INPUT
TV TV PC the INPUT TUNER TUNER
USB (SERVICE) USB (SERVICE) TUNER TUNER
INPUT INPUT INPUT 1 2 3 4 5 6 7 8 9 0 PICTURE SOUND SLEEP DISPLAY PICTURE CH+ VOL+ MUTE Select the picture mode SOUND Select the sound mode CH- VOL- SLEEP Set the Sleep Timer.
MENU OPERATION , then press Enter. Time Zone Use the Left and Right arrow to select your time zone. Use Down arrow to select Next, then press Enter. Time Zone Use Up and Down arrows to select channel scan source, then press Enter. Please follow the Setup Wizard to scan and store channels. You can perform the scan later if you choose to skip. To scan now, press Enter.
Use Up and Down arrows to select channel scan source, then press Enter. Are you Using a Cable/Satellite Box to connect your TV? Use Up and Down arrows to make selection, then press Enter. Use the Left and Right arrows to select the input source of your cable/satellite box. Use Down arrow to select Next, then press Enter. RF (TV Tuner input) is not recommended due to its poor quality analog signal. Use Down arrow to select Back and choose a higher quality input source.
INPUT
For TV Mode: OK
MENU OPERATION Color Color 27 Press ▼/▲ button to select Color, then press ◄/► button to adjust. Sharpness English Sharpness 27 Press ▼/▲ button to select Sharpness, then press ◄/► button to adjust. Tint Press ▼/▲ button to select Tint, then press ◄/► button to adjust. Tint 27 Screen Settings 1.Press ENTER when the Screen Settings item is highlighted. Then you will go to the sub-menu as following. 2.Press to select the desired menu item. Press ENTER to proceed if necessary▼/▲. 3.
120 Hz 120 Hz 120 Hz 120 Hz 120 Hz
MENU OPERATION SOUND MENU SOUND Sound Settings English Surround Mode Analog Sound Stereo Digital Sound English Other Settings Equalizer Settings MENU :Return :Select Menu ENTER :Go to Next Menu Sound Settings 1.Press ENTER when the Sound Settings item is high lighted. Then you will go to the sub-menu as following. 2.Press ▼/▲ to select the desired menu item. Press ENTER to proceed if necessary. 3.Press ◄/► to the desired level. 4.
MENU OPERATION Treble 7 Bass 7 English Balance 7 Surround Mode Press ▼/▲ button to select the item Surround Mode, then press OK button to adjust. It can set the picture to fit the screen automatically. When the Auto Wide is selected, the symbol will show as following: Surround Mode Analog Sound Press ▼/▲ button to select the item Preferred Analog Sound, then press ◄/► button to select the prefer audio when switching to an analog channel. Available Analog Sound: Stereo, Mono,SAP.
MENU OPERATION AVL Press ▼/▲ button to select the item AVL, then press ◄/► button to select ON or OFF. Auto Volume Level can set the volume automatically adjust corresponding to the input audio. Speaker Digital Audio Output Press ▼/▲ button to select the item Digital Audio Output, then press ◄/► button to select the desired digital audio output. Available digital audio output: Dolby Digital, Off, PCM.
MENU OPERATION Channel List Press ▼/▲ button to select Channel List, then press OK button to scan the Channel List. If you select the option “In Channel List” On, the channel label will display in the list. Channel List Page 1/1 English No Channels Present Please Perform Channel Search First MENU :Return :Select Menu :Page ENTER :Se lec t Cha nn el Favorite List Press ▼/▲ button to select Favorite List, then press OK button to scan the Favorite Channel List.
MENU OPERATION Auto Channel Search Press ▼/▲ button to select Auto Channel Search, then press OK button to search channel. A Channel Search Menu will appear as below. English AUTO CHANNEL SEARCH-Air Now Searching...Please Wait...
MENU OPERATION US V-CHIP Press ▼/▲ button to select US V-CHIP, then press OK button to adjust. A sub menu will appear as below. USA English Movie Rating TV Rating :Select Menu MENU :Return ENTER :Go to Next Menu Movie Rating Press ▼/▲ button to select Movie Rating, then press OK button to adjust. A sub menu will appear as below. Movie Rating G PG PG-13 R NC-17 X :Select ENTER :Lock/Unlock Press ▼/▲ button to select Rating, then press OK button to lock.
MENU OPERATION CANADA V-CHIP Press ▼/▲ button to select US V-CHIP, then press OK button to adjust. A sub menu will appear as below. CANADA English Rating C French Rating C8 + English English Rating G PG 14 + 18 + MENU :Return :Select Menu ENTER :Go to Next Menu MENU :Return :Select ENTER :Lock/Unlock French Rating G 8ans + 13ans + 16ans + 18ans + MENU :Return :Select ENTER :Lock/Unlock The operation of CANADA V-CHIP is the same as the operation of US V-CHIP.
MENU OPERATION Note: If you forget your password, you can use “1470” to enter any menu locked. Change Password Old PIN English New PIN(N/A) Confirm(N/A) ENTER :Return DIGITAL :Password Source Lock Press ▼/▲ button to select Source Lock, then press OK button to enter the sub menu. Press ▼/▲ button to select Source, then press OK button to set the Source Lock . You can’t enter the locked source if you set the Source lock.
MENU OPERATION Closed Caption Press ▼/▲ button to select the item Closed Caption, then press ◄/► button to adjust. Caption Display Off Analog Caption Type CC1 Digital Caption Type Service1 Digital CC Preset English CLOSED CAPTION Custom Digital CC Style(N/A) MENU :Return :Select Menu :On/Off Caption Display Press ▼/▲ button to select Caption Display, then press ◄/► button to select ON or OFF.
MENU OPERATION CC Size Pr ess ▼/▲ but ton to select CC Si ze, then pr ess ◄/► but ton to set . Avai labl e Si ze: Def aul t, Sm al l, St andar d, Lar ge. CC Font Press ▼/▲ but ton to sel ect , then pr ess ◄/► but ton to sel ect the Fo nt . Avai labl e type: Def aul t, Styl e0~7 . English CC Opacity Press ▼/▲ button to select CC Opacity, then press ◄/► button to select the Opacity. Available Opacity: Default, Solid, Flashing, Translucent, Transparent.
Enter the Reset password “0000”, For Modes:
MENU OPERATION PICTURE MENU PICTURE English Picture Settings Screen Settings PC Settings Color Temperature Normal Advanced Picture Settings(N/A) MENU :Return :Select Menu ENTER :Go to Next Menu Picture Settings 1.Press ENTER when the Picture Settings item is highlighted. Then you will go to the sub-menu as following. 2.Press ▼/▲ to select the desired menu item. Press ENTER to proceed if necessary. 3.Press◄/► to adjust the item to the desired level. 4.
MENU OPERATION Contrast Contrast 25 Press ▼/▲ button to select Contrast, then press ◄/► button to adjust. English Color Color 27 Press ▼/▲ button to select Colort, then press ◄/► button to adjust. Sharpness Press ▼/▲ button to select Sharpness, then press ◄/► button to adjust. Sharpness 27 Tint This option can not be adjusted. Screen Settings 1.Press ENTER when the Screen Settings item is highlighted. Then you will go to the sub-menu as following. 2.Press▼/▲ to select the desired menu item.
MENU OPERATION PC SETTINGS Auto Adjust Enter Horizontal Position Vertical Position Clock English Phase Reset MENU :Return Enter :Select Menu ENTER :Press To Enter Auto Adjust Press ▼/▲ button to select Auto Adjust, then press OK button to start auto adjusting. Horizontal Position Press ▼/▲ button to select Horizontal Position, then press ◄/► button to adjust. Horizontal Position 25 Vertical Position Press ▼/▲ button to select Vertical Position, then press◄/► button toadjust.
TROUBLESHOOTING 10. Troubleshooting Please check if you can solve problems by troubleshooting yourself . No signal No color shades Stain on the screen Double or multiple display image English Troubleshooting Control Please check that all cables are correctly plugged in. Adjust the contrast, the color and the brightness. May be the result from a lighting signal from car, motor, neon light and other electrical devices or appliances.
55 260 TUNER w/ w/o - 1320 x 300 x 916 mm - 1320 x 114 x 876 mm 42.3 49.
www.seikiworld.com © 2010 Seiki Digital Inc. All rights reserved.
