User Manual
Table Of Contents
- 1.0 INTRODUCTION
- 2.0 SAFETY
- 3.0 SPECIFICATIONS
- 4.0 OPERATION
- 4.1 FIELD OPERATION
- 4.2 TRACTOR HOOK UP
- 4.3 HYDRAULIC HOSE HOOK UP
- 4.4 HYDRAULIC MANIFOLD DESCRIPTION
- 4.5 PRE-OPERATION CHECKLIST
- 4.6 WINGING THE 7-PLEX MACHINE DOWN
- 4.7 PRIMARY OPERATION
- 4.8 PRIMARY OPERATION VARIABLES
- 4.9 SUPPLY AND DROP TUBES
- CROP RESIDUE CONSIDERATIONS
- 4.11 SEED HAWK PACKER TIRE
- 4.12 SIDE BANDING WITH ANHYDROUS AMMONIA WHILE SEEDING
- 4.13 DROP TUBE EXTENSION with NH3
- 4.14 PLACING PHOSPHATE FERTILIZER WITH SEED
- 5.0 LIQUID SYSTEM OPERATION
- 6.0 SBR HITCH
- 7.0 MAINTENANCE
- 8.0 TROUBLE-SHOOTING
- SCHEMATICS
- 9.1 2 STATION HYDRAULIC MANIFOLD (2012)
- 9.2 XL SERIES 5 PLEX MAIN HYDRAULICS (2012)
- 9.3 XL SERIES 71’8” – 10 & 72’ – 12 MAIN HYDRAULICS (2012)
- 9.4 XL SERIES 80’ & 84’ MAIN HYDRAULICS W/INTENSIFIER (2012)
- 9.5 30’ 45 SERIES HYDRAULICS (2012)
- 9.6 40’/50’/60’ 45 SERIES HYDRAULICS (2012)
- 9.7 XL SERIES 5 PLEX SCT HYDRAULICS (TBT) (2012)
- 9.8 XL SERIES 5 PLEX SCT HYDRAULICS (TBH) (2012)
- 9.9 XL SERIES 7 PLEX SCT HYDRAULICS (TBT) (2012)
- XL SERIES 7 PLEX SCT HYDRAULICS (TBH) (2012)
- 9.11 50’/60’ 45 SERIES SCT HYDRAULIC (TBT) (2012)
- 9.12 50’/60’ 45 SERIES SCT HYDRAULICS (TBH) (2012)
- 9.13 OPENER HYDRAULICS FOR SCT TOOLBARS (2012)
- 9.14 SEED BETWEEN ROW HYDRAULICS
- 9.15 SEED BETWEEN ROW HYDRAULIC MODEL
- 9.16 CONTROL BOX (SWITCH BOX)
- 9.17 TOOL BAR WIRING HARNESS
- 10.0 WARRANTY
- 11.0 NOTES
- 12.0 INDEX
Seed Hawk Manual Tool Bar Page 2
1.1 DESCRIPTION OF THE MACHINE
The Seed Hawk
Drill is a one pass seeding implement that provides accurate
depth and packing for a wide range of crop seeds with the additional capability of
optimum placement of granular, liquid or ammonia fertilizer in proximity to the
seed. The specially designed assembly arm offers accurate seed and fertilizer
placement in many field conditions, as well as on-row adjustable packing.
1.2 ILLUSTRATION OF THE MACHINE
72ft XL series model shown in Figure 1 with 7-Plex folding wing configuration
WARNING!
Some pictures in this Operator’s Manual show the machine
with shields removed to better show the subject of the picture. The Seed
Hawk
Drill must NEVER be operated with any of the shields either opened
or removed. Ensure that ALL shields are attached, closed and in good
working condition prior to operating the Seed Hawk
Drill.
IMPORTANT!
All references to “LEFT” or “RIGHT”, as used throughout this
Operator’s Manual, are determined by facing the direction of the machine’s
normal forward travel when in use.
Figure 1
