Seed Hawk Manual Tool Bar Page 47
7.5.4 Wing Hinge Points
Grease these points once a week.
Figure 31
Grease fitting
7.6 SEED/FERTILIZER KNIVES
Inspect Seed and Fertilizer Knives, Figure
32, every 10 hrs or daily for condition and
trash build up. Perform a more thorough
inspection every 100 hrs and before each
seeding season.
In muddy conditions check for mud build up
between the packer tire and the packer
arm.
Figure 31
Figure 32
