User Manual

Seed Hawk Manual Tool Bar Page 18
3.7 45 SERIES TOOLBAR 10”
10” (254 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
Folded Height
ft (m)
30’ (9.15 m) 36 3 14’ 8” (4.47 m) 13’ 0” (3.96 m)
40’ (12.19 m) 48 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
50’ (15.24 m) 60 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
60’ (18.29 m) 72 5 14’ 8” (4.47 m) 16 ’8” (5.08 m)
3.8 45 SERIES TOOLBAR 12”
12” (305 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of Seed
Rows
Number of
Sections
*Folded Width
ft (m)
Folded Height
ft (m)
30’ (9.15 m) 30 3 14’ 8” (4.47 m) 13’ 0” (3.96 m)
40’ (12.19 m) 40 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
50’ (15.24 m) 50 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
60’ (18.29 m) 60 5 14’ 8” (4.47 m) 16 ’8” (5.08 m)
3.9 45 SERIES TOOLBAR 15”
15” (381 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
Folded Height
ft (m)
30’ (9.15 m) 24 3 14’ 8” (4.47 m) 13’ 0” (3.96 m)
40’ (12.19 m) 32 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
50’ (15.24 m) 40 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
60’ (18.29 m) 78 5 14’ 8” (4.47 m) 16 ’8” (5.08 m)
*Folded width and height can be reduced by removing wing tires.
