User Manual
Table Of Contents
- 1.0 INTRODUCTION
- 2.0 SAFETY
- 3.0 SPECIFICATIONS
- 4.0 OPERATION
- 4.1 FIELD OPERATION
- 4.2 TRACTOR HOOK UP
- 4.3 HYDRAULIC HOSE HOOK UP
- 4.4 HYDRAULIC MANIFOLD DESCRIPTION
- 4.5 PRE-OPERATION CHECKLIST
- 4.6 WINGING THE 7-PLEX MACHINE DOWN
- 4.7 PRIMARY OPERATION
- 4.8 PRIMARY OPERATION VARIABLES
- 4.9 SUPPLY AND DROP TUBES
- CROP RESIDUE CONSIDERATIONS
- 4.11 SEED HAWK PACKER TIRE
- 4.12 SIDE BANDING WITH ANHYDROUS AMMONIA WHILE SEEDING
- 4.13 DROP TUBE EXTENSION with NH3
- 4.14 PLACING PHOSPHATE FERTILIZER WITH SEED
- 5.0 LIQUID SYSTEM OPERATION
- 6.0 SBR HITCH
- 7.0 MAINTENANCE
- 8.0 TROUBLE-SHOOTING
- SCHEMATICS
- 9.1 2 STATION HYDRAULIC MANIFOLD (2012)
- 9.2 XL SERIES 5 PLEX MAIN HYDRAULICS (2012)
- 9.3 XL SERIES 71’8” – 10 & 72’ – 12 MAIN HYDRAULICS (2012)
- 9.4 XL SERIES 80’ & 84’ MAIN HYDRAULICS W/INTENSIFIER (2012)
- 9.5 30’ 45 SERIES HYDRAULICS (2012)
- 9.6 40’/50’/60’ 45 SERIES HYDRAULICS (2012)
- 9.7 XL SERIES 5 PLEX SCT HYDRAULICS (TBT) (2012)
- 9.8 XL SERIES 5 PLEX SCT HYDRAULICS (TBH) (2012)
- 9.9 XL SERIES 7 PLEX SCT HYDRAULICS (TBT) (2012)
- XL SERIES 7 PLEX SCT HYDRAULICS (TBH) (2012)
- 9.11 50’/60’ 45 SERIES SCT HYDRAULIC (TBT) (2012)
- 9.12 50’/60’ 45 SERIES SCT HYDRAULICS (TBH) (2012)
- 9.13 OPENER HYDRAULICS FOR SCT TOOLBARS (2012)
- 9.14 SEED BETWEEN ROW HYDRAULICS
- 9.15 SEED BETWEEN ROW HYDRAULIC MODEL
- 9.16 CONTROL BOX (SWITCH BOX)
- 9.17 TOOL BAR WIRING HARNESS
- 10.0 WARRANTY
- 11.0 NOTES
- 12.0 INDEX
Seed Hawk Manual Tool Bar Page 16
3.3 TRACTOR REQUIREMENTS
Tractor Hydraulic Circuit Requirements
Circuit #1 Shank Lift/Lower (intermittent)
<40’ (12.2 m) Flow Rate 2-3 gal-US/min (7.6-11.3 L/min)
40’+ (12.2 m) Flow Rate 3-4 gal-US/min (11.3-18.9 L/min)
Circuit #2 Hydraulic Manifold (continuous)
Model: SH Tool Bar Flow Rate 3-4 gal-US/min (11.3-18.9 L/min)
Rear Steering (option) 3 gal-US/min (11.3 L/min)
SBR Hitch (option) 2-3 gal-US/min (7.6-11.3 L/min)
Low Pressure Tank Line(s) Tractor Reservoir 3-5 gal-US/min (11.3-18.9
L/min)
IMPORTANT!
The low pressure return must enter tractor reservoir directly.
