Seed Hawk Manual Tool Bar Page 12
DANGER!
HAZARD. Stay away from
ELECTROCUTION
power lines when transporting,
extending or folding implement.
Electrocution can occur without
contacting power lines, Figure 7.
2.9.2 Safety Sign Information
Safety Sign Legibility
All safety signs applied to the implement must be visible and legible. Keep dust
and dirt cleared from safety signs and ensure that visibility is not obscured.
Safety Sign Replacement
Replacement safety signs may be ordered through your dealer or distributor.
Contact Seed Hawk, Inc if you are unable to obtain replacement safety signs from
a dealer or distributor.
Damaged or Deteriorated Safety Signs
Remove and replace any safety signs that have either been damaged or show
signs of deterioration.
Safety Signs on Replacement Parts
Ensure that parts or components that are replaced on the implement that had a
safety sign attached originally include a safety sign.
Figure 7
