Seed Hawk Manual Tool Bar Page 11
2.9.1 Applied Safety Signs
CAUTION!
before operating machine. Heed all
instructions before operating machine,
Read Operator’s Manual
Figure 4.
WARNING
FLUID HAZARD. Relieve pressure
! HIGH PRESSURE
on system before disconnecting,
repairing or adjusting. Wear proper
hand and eye protection when
searching for leaks. Keep all
components in good repair, Figure 5.
WARNING!
HAZARD. Stay away from beneath
OVERHEAD WING
Wings when they are in the raised
position or are being lowered.
Keep others away, Figure 6.
Figure 4
Figure 5
Figure 6
