User Manual
Table Of Contents
- 1.0 INTRODUCTION
- 2.0 SAFETY
- 3.0 SPECIFICATIONS
- 4.0 OPERATION
- 4.1 FIELD OPERATION
- 4.2 TRACTOR HOOK UP
- 4.3 HYDRAULIC HOSE HOOK UP
- 4.4 HYDRAULIC MANIFOLD DESCRIPTION
- 4.5 PRE-OPERATION CHECKLIST
- 4.6 WINGING THE 7-PLEX MACHINE DOWN
- 4.7 PRIMARY OPERATION
- 4.8 PRIMARY OPERATION VARIABLES
- 4.9 SUPPLY AND DROP TUBES
- CROP RESIDUE CONSIDERATIONS
- 4.11 SEED HAWK PACKER TIRE
- 4.12 SIDE BANDING WITH ANHYDROUS AMMONIA WHILE SEEDING
- 4.13 DROP TUBE EXTENSION with NH3
- 4.14 PLACING PHOSPHATE FERTILIZER WITH SEED
- 5.0 LIQUID SYSTEM OPERATION
- 6.0 SBR HITCH
- 7.0 MAINTENANCE
- 8.0 TROUBLE-SHOOTING
- SCHEMATICS
- 9.1 2 STATION HYDRAULIC MANIFOLD (2012)
- 9.2 XL SERIES 5 PLEX MAIN HYDRAULICS (2012)
- 9.3 XL SERIES 71’8” – 10 & 72’ – 12 MAIN HYDRAULICS (2012)
- 9.4 XL SERIES 80’ & 84’ MAIN HYDRAULICS W/INTENSIFIER (2012)
- 9.5 30’ 45 SERIES HYDRAULICS (2012)
- 9.6 40’/50’/60’ 45 SERIES HYDRAULICS (2012)
- 9.7 XL SERIES 5 PLEX SCT HYDRAULICS (TBT) (2012)
- 9.8 XL SERIES 5 PLEX SCT HYDRAULICS (TBH) (2012)
- 9.9 XL SERIES 7 PLEX SCT HYDRAULICS (TBT) (2012)
- XL SERIES 7 PLEX SCT HYDRAULICS (TBH) (2012)
- 9.11 50’/60’ 45 SERIES SCT HYDRAULIC (TBT) (2012)
- 9.12 50’/60’ 45 SERIES SCT HYDRAULICS (TBH) (2012)
- 9.13 OPENER HYDRAULICS FOR SCT TOOLBARS (2012)
- 9.14 SEED BETWEEN ROW HYDRAULICS
- 9.15 SEED BETWEEN ROW HYDRAULIC MODEL
- 9.16 CONTROL BOX (SWITCH BOX)
- 9.17 TOOL BAR WIRING HARNESS
- 10.0 WARRANTY
- 11.0 NOTES
- 12.0 INDEX
Seed Hawk Manual Tool Bar Page 4
2.0 SAFETY
2.1 SAFETY ALERT SYMBOL
The Safety Alert Symbol is intended to capture the attention of the machine
operator of important safety information both published in the Operator’s Manual
and applied to the machine. Any time a Safety Alert Symbol is seen, it means that
associated information is provided for recognizing, appropriately responding to and
avoiding potentially hazardous situations.
An equilateral triangle surrounding an exclamation point indicates a potential
hazardous situation. Information included on a safety sign or printed in the
Operator’s Manual describes the hazardous situation and indicates appropriate
response and/or avoidance procedures.
REMEMBER:
ACCIDENTS DISABLE AND KILL
ACCIDENTS ARE COSTLY
ACCIDENTS CAN BE AVOIDED
2.1.1 Signal Words
Indicates an imminently hazardous situation that,
if not avoided,
DANGER
WILL
result in death or serious
injury if proper precautions are not taken.
WARNING
Indicates a potentially hazardous situation that, if
not avoided,
COULD
result in death or serious
injury if proper precautions are not taken.
CAUTION
Indicates a potentially hazardous situation that, if
not avoided,
MAY result in minor or moderate
injury if proper practices are not taken, or, serves
as a reminder to follow appropriate safety
practices.
This Safety Alert Symbols Means:
ATTENTION!
BE ALERT!
YOUR SAFETY IS INVOLVED!
