Instruction Manual

LIQUID SYSTEM CALIBRATION
PUMP SETTINGS
28L26 Rear Axle
28L26 Rear Axle
Gear Ratio
3.11 3.11 3.73 3.73 3.73 3.73 4.98 4.98 4.98 4.98 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4
Seeder Width20222426283032343638404244464850525456586062646684
Pump Setting
2
7.0 7.0 7.0 7.0 6.0 6.0 7.0 7.0 6.0 6.0 7.0 7.0 7.0 6.0 6.0 6.0 6.0 5.0 5.0 5.0 5.0 5.0 5.0 4.0 4.0
3
10.6 10.3 10.6 10.3 9.1 8.9 10.6 10.4 9.2 9.0 10.7 10.5 10.4 9.2 9.1 8.9 8.8 7.7 7.6 7.5 7.5 7.4 7.3 6.2 5.8
4
14.2 13.5 14.2 13.6 12.1 11.7 14.2 13.7 12.4 12.0 14.4 14.0 13.7 12.4 12.1 11.9 11.7 10.5 10.3 10.1 9.9 9.7 9.6 8.5 7.5
5
17.7 16.8 17.7 16.9 15.2 14.6 17.7 17.1 15.5 15.0 18.0 17.5 17.1 15.6 15.2 14.8 14.5 13.2 12.9 12.6 12.4 12.1 11.9 10.7 9.3
6
21.3 20.0 21.3 20.2 18.3 17.4 21.3 20.5 18.7 18.0 21.7 21.0 20.4 18.8 18.3 17.8 17.3 15.9 15.5 15.2 14.8 14.5 14.2 12.9 11.0
7
24.9 23.3 24.9 23.5 21.4 20.3 24.9 23.9 21.9 21.1 25.4 24.6 23.8 22.0 21.4 20.7 20.2 18.7 18.2 17.7 17.3 16.9 16.5 15.2 12.8
8
28.5 26.5 28.5 26.8 24.4 23.2 28.5 27.2 25.1 24.1 29.1 28.1 27.1 25.2 24.4 23.6 23.0 21.4 20.8 20.2 19.7 19.2 18.8 17.4 14.5
9
32.1 29.8 32.1 30.1 27.5 26.0 32.1 30.6 28.3 27.1 32.8 31.6 30.5 28.4 27.5 26.6 25.8 24.1 23.4 22.8 22.2 21.6 21.1 19.6 16.3
10
35.6 33.0 35.6 33.4 30.6 28.9 35.6 34.0 31.4 30.1 36.4 35.1 33.8 31.6 30.6 29.5 28.6 26.8 26.0 25.3 24.6 24.0 23.4 21.8 18.0
Gear Ratio
3.11 3.11 3.11 3.11 3.11 3.11 3.73 3.73 3.73 4.98 4.98 4.98 4.98 4.98 4.98 4.98 6.4
Seeder Width3638404244464850525456586062646684
Pump Setting
2
8.08.07.07.07.06.07.07.07.08.08.08.08.07.07.07.07.0
3
12.0 11.8 10.6 10.4 10.3 9.1 10.6 10.4 10.3 12.2 12.1 12.0 11.8 10.7 10.6 10.5 10.5
4
16.0 15.5 14.2 13.8 13.5 12.2 14.2 13.9 13.6 16.5 16.2 15.9 15.6 14.4 14.2 13.9 14.0
5
19.9 19.3 17.7 17.2 16.8 15.3 17.7 17.3 16.9 20.7 20.3 19.9 19.5 18.1 17.7 17.4 17.5
6
23.9 23.1 21.3 20.6 20.0 18.4 21.3 20.8 20.2 25.0 24.4 23.8 23.3 21.8 21.3 20.9 21.0
7
27.9 26.9 24.9 24.1 23.3 21.6 24.9 24.2 23.5 29.2 28.5 27.8 27.1 25.5 24.9 24.4 24.6
8
31.9 30.6 28.5 27.5 26.5 24.7 28.5 27.6 26.8 33.4 32.5 31.7 30.9 29.1 28.5 27.8 28.1
9
35.9 34.4 32.1 30.9 29.8 27.8 32.1 31.1 30.1 37.7 36.6 35.7 34.7 32.8 32.1 31.3 31.6
10
39.8 38.2 35.6 34.3 33.0 30.9 35.6 34.5 33.4 41.9 40.7 39.6 38.6 36.5 35.6 34.8 35.1
Application Rate in US Gallons per Acre
Twin Piston
Application Rate in US Gallons per Acre
4450 Model John Blue Pump
Single Piston
4950 Model John Blue Pump
