SEED HAWK GRANULAR AND LIQUID TANKS MANUAL 2008 Manual Version 1 Retail Price $36.00 CDN ($32.
Tank Manual Table of Contents Page Introduction Machine Serial Number Seed Hawk Warranty Warranty Registration Form (Tear out ) 3-4 Safety Alert Symbols Operator Responsibility General Safety Practice Maintenance Safety Hydraulic Safety Transport Safety Storage Safety Tire Safety Safety Sign Location Applied Safety Signs Safety Sign Information Operation Fill auger Fill auger positioning for filling tank Fill auger position for unloading Fill auger Transport position Tractor Requirements Fan hoses and
Table of contents continued Liquid System Operation System flow description Filling the liquid fertilizer tank Checking fertilizer runs Applying liquid fertilizer Agitate liquid fertilizer Liquid fill pump Liquid orifice manifold Electric liquid diverter valve Liquid fertilizer application rates Liquid pump settings (28L26 tires ) Liquid pump settings (30.
INTRODUCTION Congratulations on your choice of a Seed Hawk£ Tank to complement your farming operation. This implement has been designed and manufactured to meet the agricultural industry’s need for precise direct seeding. All persons authorized to operate this implement should read and understand the contents of this Operator’s Manual, especially the Safety section.
INTRODUCTION DESCRIPTION OF THE MACHINE The Seed Hawk£ tank is a single axle tank which is designed to be a tow-between or a tow-behind except the 800 tank which is only a tow-behind. The 400 tank is a 400 bushel two compartment tank with a 60/40 split. A 100 bushel third tank and meter can be added to the 400 to make it a 500 bushel cart mounted on board the tool bar or as a stand alone tank. The 600 bushel and 800 bushel tanks both have three compartments and a standard two-fan configuration.
INTRODUCTION MACHINE SERIAL NUMBER The serial number plate, FIG. 2, is located on the cradle near the front of the tank. Record the tank model and serial number in the spaces provided below. Use these numbers when contacting the dealer for repair parts or service assistance. Model #: _____________________ Serial #: _____________________ FIG.
INTRODUCTION SEED HAWK INC. WARRANTY All Seed Hawk products are warranted for one (1) year against defects in material and workmanship, and to perform according to specifications when such products are properly assembled, installed, used, and maintained. Seed Hawk’s frame is warranted for five (5) years or 25,000 acres, whichever comes first, against defects in material and workmanship, and to perform according to specifications when such products are properly used and maintained.
Seed Hawk® Owner Product Registration Model Number: Serial Number: ___________ ___________ Purchase Date: Delivery Date: ___________ ___________ Mobile/Cell: Fax: ___________ ___________ ___________ ___________ ___________ ___________ ___________ ___________ Mobile/Cell: Fax: ___________ ___________ ___________ ___________ ___________ ___________ ___________ ___________ ___________ Customer: Name: Address: City/Town: Province/State: Postal Code/Zip: Country: Telephone: E-Mail: ___________ _________
SAFETY SAFETY ALERT SYMBOL The Safety Alert Symbol is intended to capture the attention of the machine operator of important safety information both published in the Operator’s Manual and applied to the machine. Any time a Safety Alert Symbol is seen, it means that associated information is provided for recognizing, appropriately responding to and avoiding potentially hazardous situations. An equilateral triangle surrounding an exclamation point indicates a potential hazardous situation.
SAFETY OPERATOR RESPONSIBILITY Remember, YOU, the operator, are responsible for the safe operation, adjustment, maintenance and repair of this Seed Hawk drill. It is the responsibility of the owner, or authorized person in charge, to ensure all persons who operate, adjust, maintain and/or repair this implement be familiar with the information provided in this Operator’s Manual before performing any of the tasks listed above. A safe operator is the key to safety.
SAFETY GENERAL SAFETY PRACTICES x Read and understand the contents of this Operator’s Manual prior to operating, adjusting, maintaining and/or repairing the implement. x Locate, read and understand all safety signs applied to the implement before performing any tasks. x Review the contents of this Operator’s Manual at least annually, and, any time a new person is assigned to perform any task with the implement.
SAFETY MAINTENANCE SAFETY x Read and understand all information provided in this Operator’s Manual covering operation, adjustment, maintenance and repair prior to performing any of these tasks. x Plan work to ensure proper tools, equipment and personal protective equipment is available prior to working on implement. x Wear appropriate clothing when performing tasks around the implement.
SAFETY HYDRAULIC SAFETY x Ensure that all hydraulic system components are kept clean and in proper working condition. x Periodically inspect condition of hydraulic hoses, lines and components and remove and replace any parts showing damage or deterioration. x Use only repair or replacement parts specified by the manufacturer. x Make repairs manufacturer.
SAFETY TRANSPORT SAFETY x Ensure that the drill is attached to the tractor properly. x Ensure drawbar hitch pin retainer is in place and functioning properly. x Ensure safety tow chain is securely attached to the tractor. x Ensure all lighting and implement marking devices are intact and visible. x Ensure that the implement is properly marked according to local road regulations. x Read all local road traffic regulations. x Do not exceed 32 km/h (20 mi/hr).
SAFETY SAFETY SIGNS LOCATION OF SAFETY SIGNS ON IMPLEMENT FIG.
SAFETY APPLIED SAFETY SIGNS CAUTION! Read Operator’s Manual before operating machine. Heed all instructions before operating machine. FIG. 4 WARNING! HIGH PRESSURE FLUID HAZARD. Relieve pressure on system before disconnecting, repairing or adjusting. Wear proper hand and eye protection when searching for leaks. Keep all components in good repair. FIG. 5 WARNING! OVERHEAD WING HAZARD Stay away from beneath wings when they are in the raised position. FIG.
SAFETY DANGER! MOVING PART HAZARD. Keep away. Moving parts can crush and dismember. DO NOT operate without guards and shields in place. Disconnect and lockout power source before adjusting and servicing. FIG. 7 DANGER! MOVING PART HAZARD. Rotating spinners. DO NOT service or make adjustments without first: x Stopping power source. x Ensuring bystanders are at least 100 ft (30 m) away from machine. FIG. 8 ENTANGLEMENT DANGER! HAZARD. Keep hands, feet, and clothing away from auger intake. FIG.
SAFETY SAFETY SIGN INFORMATION Safety Sign Legibility All safety signs applied to the implement must be visible and legible. Keep dust and dirt cleared from safety signs and ensure that visibility is not obscured. Safety Sign Replacement Replacement safety signs may be ordered through your dealer or distributor. Contact Seed Hawk, Inc if you are unable to obtain replacement safety signs from a dealer or distributor.
OPERATION FILL AUGER – 10 inch FIG 1 DANGER! ELECTROCUTION HAZARD. Use extreme caution when moving the auger, especially near power lines. It is not necessary to come into direct contact with an overhead power line for electrocution to occur. Serious injury or death will result WARNING! ENTANGLEMENT HAZARD. Keep arms, hands and legs away from auger intake. Wear appropriate fitting clothing when working in the vicinity of an auger.
OPERATION POSITIONING THE AUGER 1. Ensure that the area in the vicinity of auger operation is free of obstructions and that all bystanders, especially children, are kept at a safe distance before positioning or operating the auger. 2. Unfold auger and position it where filling and emptying the tank is optimal. 1 FIG 1. 1 FIG. 1 3. Lock the auger arm into position so auger will not move if positioned on unlevel ground 1 FIG. 2. 4. Allow hopper to come into contact with the ground before final positioning.
OPERATION 3. If circuit is already engaged direct the fan diverter valve to the fill auger position from the fan location. 1 FIG 4. 1 FIG. 4 4. The handle on the auger tube is to operate the auger flighting in a forward or reverse motion. 1 FIG 5. 1 FIG. 5 AUGER POSITION FOR UNLOADING AIR TANK 1. FIG. 6 Unlock the second auger arm to allow the auger tube to pivot under either of the tank compartments in order to empty them. 1. FIG 6.
OPERATION AUGER TRANSPORT POSITION IMPORTANT: Fill auger should always be secured for transport, no matter how short the distance. 1. Position the auger so that the tube is resting on the locking mechanism at the back of the tank and the discharge spout is hanging freely. 1 FIG 7. 1 FIG. 7 2. The locking mechanism must be use when transporting at all times. 1 FIG 8. 1 FIG. 8 NOTE: It is easier to move the auger when on level ground. . 2. Push the auger diverter valve back to the fan position. FIG 9.
OPERATION Fan(s) (optional) (Two hoses with blue bands) Connect the pair of 3/4” hydraulic lines to supply the hydraulically driven fan motor. The pressure line is marked with a narrow blue band, and the return line is marked with a wide blue band. This tractor lever is locked in full pressure position while seeding. Case Drain(s) (Two hoses with yellow bands) You must also connect the case drain lines (yellow bands) to return hydraulic fluid back to the tractor reservoir.
OPERATION Metering Roller The metering roller provided in each compartment is designed to accommodate every / all product for seeding small oil seeds to large pulses as well as granular fertilizer. There are sections that make up the roller which can be replaced if damage occurs. There are two colored roller sections on some meters. The red sections have an 11% less displacement than the black sections.
OPERATION SEEDHAWK PRESSURIZED METERING SYSTEM FAN(S) Some models are configured with a single fan while others may be configured with dual fans. Fans are driven by hydraulic motors with speed controlled by the tractor hydraulic flow control system. Fan speed is indicated on the monitor panel in the cab. Set fan speed to effectively transport the seed. A reminder that higher fan speeds will increase seed bounce and possibly damage the seed. Higher fan speeds also require more power input from the tractor.
OPERATION CHECKING AIR AND PRODUCT FLOW The test procedure outlined below serves as a guideline for ensuring proper fan speed for effective delivery of product: 1. Remove hose(s) from an outside opener and temporarily attach to the frame of the seeder with the hose looping no more than 12 in (300 mm) below the frame. 2. Begin seeding at normal field speed and observe distance product discharges from hose(s) attached to the frame.
OPERATION NOTE: In the case of a single fan configuration used to double-shoot product, follow the above procedure and adjust the position of the air damper, 1, FIG. 46, to set an effective air flow for each product. IMPORTANT: DO NOT set fan speed above 5000 rev/min. Excessive fan speed will damage the fan drive motor and requires more power from the tractor hydraulic system. GROUND DRIVE METERING The ground drive metering system is engaged by activating an electric clutch, 1 FIG. 34.
CALIBRATION There is a funnel provided that hangs on the bottom of the meter you are calibrating. First take off the bottom plate of the meter and slide on the funnel. Set the Seed Hawk pail under the funnel to catch your product. FIG 4. NOTE: Prime your roller before proceeding to turn the crank handle to meter out product. NOTE: When weighing your pail with product, ensure the pail is zeroed out prior to metering product.
CALIBRATION Here in Fig 1 & 2 are some pictures showing where the setting for 37 is on the Vaderstad Gearbox from the calibration example. Ensure the half width shut offs are set for small or large seed settings prior to priming the roller. FIG 1 1 FIG 2 FIG 3 2 3 Another look at the Vaderstad gearboxes. NOTE: Ensure the input shaft pins on the gearbox or gearboxes are taken out while calibrating one compartment at a time.
CALIBRATION This illustration shows the diverter valve in the calibration position and the lower air stream position. The product flows under the roller and the diverter valve diverts the product into the lower airstream. This illustration shows the diverter valve in the up position. The product flows under the roller and is diverted into the top airstream.
CALIBRATION Product and fan air flow directional diagram for tow between and tow behind tanks:
LIQUID SYSTEM OPERATION SEED HAWK LIQUID FERTILIZER SYSTEM 6 1 4 12 13 10 11 14 3 5 2 7 8 15 9 FIG. 39 FIG. 39.
LIQUID SYSTEM OPERATION SYSTEM FLOW DESCRIPTION The metering pump, ground driven by the metering wheel, draws liquid fertilizer first through the flow valve, then the main filter. The liquid fertilizer is then pumped to the distribution system. A gauge indicates the operating pressure. Select the appropriate size orifice to adjust the liquid fertilizer delivery pressure.
LIQUID SYSTEM OPERATION FILLING THE LIQUID FERTILIZER TANK To fill the liquid fertilizer tank: 3 2 1. Remove fill cap, 1 FIG. 40, and attach fill hose from liquid fertilizer supply source to the quick coupler. 2. Open fill valve, 2 FIG. 40 and begin filling tank by starting fill pump. 1 3. When tank is near full, shut off fill pump and close main valve, 3, FIG. 40. FIG. 41 A closer picture of fill plumbing. FIG.40 FIG.
LIQUID SYSTEM OPERATION CHECKING FERTILIZER RUNS Perform the following test to ensure that each fertilizer run is functioning properly: 1. Ensure that tank is at least partially filled with either water or liquid fertilizer. 2. Lower metering wheel and proceed forward about 20 - 30 ft (6 - 9 m). 3. Stop tractor and look at ground behind each opener to ensure liquid fertilizer is discharged behind each run. APPLYING FERTIILIZER LIQUID To apply liquid fertilizer, ensure that main flow valve, 1 FIG.
LIQUID SYSTEM OPERATION AGITATE LIQUID FERTILIZER It is recommended that the contents in the liquid fertilizer tank be agitated for a few minutes before seeding if liquid fertilizer in the tank has sat for more than eight hours. NOTE: Phosphate is heavier than other nutrients and will tend to settle to the bottom of the tank. 2 To agitate tank contents: 1. Remove fill cap, 1 FIG. 43. 2. Attach suction line of fill pump to quick coupler at the bottom of the tank. 3.
LIQUID SYSTEM OPERATION A liquid fill pump is an option when the liquid onboard tank is ordered. It is usually located at the rear of the liquid tank. Example of a double orifice liquid Kit. One row of orifices are #49’s and the other orifices are #30’s. The grower can open either, or both, at any time. The grower would change the orifice selection to maintain system pressure. 30-35psi is an optimal pressure for this liquid system.
LIQUID SYSTEM CALIBRATION LIQUID FERTILIZER APPLICATION RATES JOHN BLUE£ PUMP Perform the following steps to ensure that the liquid fertilizer pump is calibrated properly: 1. Set the pointer, 1 FIG. 18, on the metering pump to a setting that corresponds to the desired liquid application rate. 2. Before seeding, accurately measure or carefully estimate the amount of liquid in the liquid fertilizer tank and note the beginning area reading on the monitor display. 3. Seed a significantly large area.
2 3 4 5 6 7 8 9 10 Pump Setting 26 28 30 32 36 38 40 42 44 6.4 46 6.4 48 6.4 50 6.4 52 6.4 54 6.4 56 6.4 58 6.4 60 6.4 62 6.4 64 6.4 66 6.4 84 6.4 7.0 6.0 6.0 6.0 6.0 5.0 5.0 5.0 5.0 5.0 5.0 4.0 4.0 Application Rate in US Gallons per Acre 34 7.0 7.0 7.0 7.0 6.0 6.0 7.0 7.0 6.0 6.0 7.0 7.0 24 6.4 40 42 44 46 48 52 54 56 58 60 62 64 66 Application Rate in US Gallons per Acre 50 84 6.4 39.8 38.2 35.6 34.3 33.0 30.9 35.6 34.5 33.4 41.9 40.7 39.6 38.
2 3 4 5 6 7 8 9 10 Pump Setting 22 24 26 28 30 32 36 38 40 42 44 46 48 50 Application Rate in US Gallons per Acre 34 52 54 56 58 60 62 64 66 84 40 42 44 46 48 52 54 56 58 60 62 64 66 Application Rate in US Gallons per Acre 50 84 43.6 40.8 36.7 35.3 34.1 32.0 41.3 41.3 40.0 38.8 36.7 35.6 34.7 43.5 41.4 40.4 31.4 39.3 36.7 33.0 31.8 30.7 28.8 37.1 37.1 36.0 35.0 33.0 32.1 31.2 39.2 37.3 36.4 28.3 35.0 32.6 29.3 28.2 27.3 25.5 33.0 33.0 32.0 31.1 29.3 28.5 27.8 34.
LIQUID SYSTEM CALIBRATION LIQUID PUMP GEAR RATIOS Gearing for Pumps Driven from the Rear Axle 28L26 Axle LM-4450 Pump Ratio Hub to Hex Shaft 3.11 3.73 4.98 6.4 56 - 10 56 - 10 56 - 10 56 - 10 Hex Shaft to Pump 10 12 16 16 - Seeder widths (2 ft increments) 18 18 18 14 20 - 22 24 - 26 - 28 - 30 32 - 34 - 36 - 38 40 - 84 inclusive LM-4950 Pump Ratio Hub to Hex Shaft 3.11 3.73 4.98 6.
LIQUID SYSTEM CALIBRATION ORIFICE SELECTION TABLE NOTE: Table data is based on a ground speed of 5 mph (8 kph) System Pressure (psi) 10 20 30 40 50 60 Application rate for 10" spacing (US gallons per acre) 4916 - 30 4916 - 49 Combined 5.7 14.6 20.3 7.4 22.2 29.6 9.1 27.2 36.3 10.5 31.4 41.9 11.7 35.1 46.8 13.5 40.2 53.7 System Pressure (psi) 10 20 30 40 50 60 Application rate for 12" spacing (US gallons per acre) 4916 - 30 4916 - 49 Combined 5.1 13.3 18.4 6.8 17.5 24.3 8.4 21.5 29.9 9.6 24.7 34.3 10.
SPECIFICATIONS HARDWARE TORQUE SAE Bolt Diameter inches 1/4 5/16 3/8 7/16 1/2 9/16 5/8 3/4 7/8 1 Bolt Torque SAE 2 N·m (lb-ft) 8 (6) 13 (10) 27 (20) 41 (30) 61 (45) 95 (70) 128 (95) 225 (165) 230 (170) 345 (225) SAE 5 N·m (lb-ft) 12 (9) 25 (19) 45 (33) 72 (53) 110 (80) 155 (115) 215 (160) 390 (290) 570 (420) 850 (630) SAE 8 N·m (lb-ft) 19 (12) 36 (27) 63 (45) 100 (75) 155 (115) 220 (165) 305 (220) 540 (400) 880 (650) 1320 (970) Metric Bolt Diameter mm M3 M4 M5 M6 M8 M10 M12 M14 M16 M20 M24 M30 M36 Bolt
SPECIFICATIONS Tire Pressure Use the following chart to check and adjust, if necessary, tire pressure. Tire Size 4.80-8 11L15 12.5L15 19.0/45-17 500/45-22.5 28L26 30.5L32 Recommended Tire Air Pressure lb/in2 (psi) kPa 18 124 45 310 45 310 45 310 48 330 32 220 32 220 NOTE: Proper inflation of tire pressure contributes to longer tire life and proper flotation for field operations. Tire inflation pressures listed are recommended initial settings.
221 3/8" 1568 lbs. 34 1/4" 89" 193 3/8" 13' 6" Onboard 62 1/2" 363 lbs. 23 1/4" 87 3/16" 41 1/2" Tank Length (in.) Cradle Weight (lbs.) Cradle Height (in.) Cradle Width (in.) Cradle Length (in.) 5638 lbs. 146 bu. 254 bu. 1418 lbs. 100 bu. Tank 1 Bushels Tank 2 Bushels Tank 3 Bushels 89" 34 1/4" 1182 lbs. 158 7/8" 90 1/2' 90 3/4" Total Tank Weight Complete Weight 146 bu. 254 bu. 100 bu. 12' 6" 90 1/2" 90 1/2" Tank Width (in.
MAINTENANCE MAINTENANCE SCHEDULE Item Procedure check 9 Wheel Hubs main frame Metering System sprockets and chains Metering Components Seed Hawk Fan System intake Fan System fan blades Fill Auger System 10 in Fill Auger System pillow block bearings Fill Auger System universal joints Tank Return Line open - drain in pail Tires air pressure NOTE: Frequency lube 6 clean change S Reference Notes hours 5 6 100 6 25 100 9 10 9 10 100 6 10/100 6 10/100 9 100 9 10 100 hr or
