Instruction Manual

9 | SecurityMan
iCamDVR Specications
Video format: NTSC/PAL (selectable).•
Resolution: 320x240/ 640x480(NTSC), 352x288/ •
704x576(PAL).
Maximum Frame rate per channel: 30 ftp (NTSC) 4 •
channels; 7.5fps each channel (option), 25 fps (PAL) 4
channels; 6.25fps each channel.
Screen set: resolution 1024_768, color quality 16 bits or •
32 bits @ 96% DPI
Video Resolution: 320x240 or 640x480 (NTSC)•
Compression code rate: 50kbps – 1.2Mbps•
Compression format: MPEG4•
4 x RCA Video Input•
2 x Audio Input Channel (select one)•
Video Output: USB 2.0 (to PC)•
Recorder Media: HDD, USB Disk, CD-RW•
Record Mode: Motion, Schedule, Manual •
Network Protocol: TCP/IP•
PTZ Protocol: Null, Lilin, Minking, Neon, PelcoD, PelcoP, •
Star, Vido, and VISCA
Web Based remote liveview and playback from Internet •
Explorer Web Browser.
