Instruction Manual
59 | SecurityMan
Mode” and all 4 cameras will playback in four split screen,
the channel modes are illustrated below:
The default playback mode is Single Channel Mode
which display Camera 1. To change from Camera 1 to
other cameras, click on the “Single Channel Mode”
button and the following channel conguration window
will appear:
Select any one of the four channels from Channel Cong-
uration Windows, please a check mark on “Audio” if the
selected camera supports audio recording, and then click
“OK” to accept changes.
Click to select the Four Channel Mode button to playback
all 4 channels at the same time and the following Channel
Conguration Window will appear:
Select any combination of the 4 channels or all 4 chan-
nels and select the audio channel that corresponds to the
camera audio setup to playback , then click “OK” to accept
changes and starts playback.
Control Buttons and functionality:
Play/Pause –– use to start playback and to pause
during playback.
Stop –– use to stop the playback.
Play Speed (Slow) –– use to play the playback 6
times slower than normal speed.
Play Speed (Fast) –– use to play the playback 4
times faster than normal speed.
One Channel Mode Four Channel Mode
Figure 92 - One Channel Select
Figure 93 -Four Channel Select
