Set Motion Detection Sensitivity
Click and drag the Sensitivity bar to adjust value for
motion detection Sensitivity. Adjust the Sensitivity
accordingly to preference, sensitivity ranges from 0 to
100, 100 being the most sensitive level and 0 is the least
sensitive level.
Alarm Conguration Panel
The Alarm Conguration Panel as its name states is
where alarm inputs and alarm outputs are congured.
There are a total of three tabs under Alarm Conguration
Panel and they are labeled as Alarm Output, AutoMail,
and Emap, which will be explain in more detail below.
Also under the Alarm Conguration Panel is Buzzer
which uses the computer’s built-in buzzer as an alarm
output whenever there are limited of available disk space
in the system or motion triggers, Pre-Alarm Record to
record video event before the actual event occurred, Full
Screen Alarm is whenever motion triggered the triggered
camera channel will become single full screen mode for
a period of time, Motion holding time is motion record-
ing time per event(s) and nally Disk shortage alarm
provides alarm buzzer via computer built-in buzzer and/or
email administrator via smtp/pop server. Please proceed
to gure 36 and gure 37 below for more detail explana-
tions.
Relative Alarm Conguration Explanations:
Buzzer
Select this option to enable and utilizes the computer’s
built-in buzzer so that when motion alarm triggers or there
is a shortage in hard drive spaces, the built-in buzzer in the
computer will output a loud beeping/buzzing sound. The
buzzer time can be setup between 5, 10, and 20 seconds of
intervals.
Disk Shortage Alarm
If the hard drive’s available percentage space is less than
the set value percentage value, the buzzer will beep and/
or email the system administrator. This is Buzzer and Au-
toMail dependent, meaning the Buzzer and/or AutoMail
has to be selected/checked, see Buzzer explanation above
and AutoMail below for better understanding. Disk short-
age alarm setting ranges from 0%, 25%, 50%, and 75%.
The default percentage is set to 25%.
Figure 36 - Alarm Conguration
